Send bottles of rotary
Technical parameters:
1.Suitable specifications: according to the sample provided by customers products
2.Turntable material: stainless steel, 1 meter in diameter
3.Bottle delivery capacity: about 80 bottles/min (50ML bottles)
4.Driving motor: 370W variable frequency speed regulating motor
16 head peristaltic pump filling machine
1.Quantity of filling head: 16
2.Filling capacity: 30mL-150ml
3.Filling form: peristaltic pump quantitative multi filling
4.Filling speed: about 80 bottles/min (50 ml bottles are calculated, depending on the actual bottle size and material)
5.Filling accuracy: ±1%
6.Material: stainless steel filling frame
7.Program control: PLC+ touch screen
8.Filling nozzle and trough contact liquid parts material: 304# stainless steel, silicone tube
9.Pressure: 0.6-0.8 MPa
10.Conveyor belt :82mm wide POM chain belt, speed 0-15m/min, ground height 850mm±25mm
11.Conveying motor: 750W variable frequency speed regulating motor
12.Power: about 2KW/AC220V 50/60Hz
Double position capping machine
Technical parameters:
1.Suitable specification: according to the sample provided by the customer
2.Cap type: electric clamp
3.Speed: approx. 80 bottles/min
4.Material: The frame adopts stainless steel
5.Program control: shared with lower cover machine
6.Machine power: about 1KW
7.Pressure: 0.6-0.8 MPa
8.Conveyor belt: 82mm wide POM chain belt, speed 0-15m/min, ground height 850mm±25mm
Capping machine
Technical parameters:
1. Suitable for bottle specifications: according to the sample provided by customers
2. Lower cover form: manually put the outer cover
3. Gland form: pneumatic gland
4. Speed: about 80 bottles/min
5. Material: The frame is made of stainless steel
6. Program control: Frequency converter speed control
7. Conveyor belt: 82mm wide POM chain belt, speed 0-15m/min, ground height 850mm±25mm
8. Machine power: about 1.5KW
