2.5mm Spiral Cross Blade Concertina Razor Coil For Razor Barbed Fence
Description
Blade barbed wire is by the wide hot dip galvanized steel sheet material after professional stamping machine into the blade shape of strip steel, again by another machine after stamping plate coated steel wire, to make them more hard and more easy to install is not easy to deformation, spiraling again after the customer requirement to decide whether to take card, card buckle is connect the two adjacent wire, make its after open the double helix structure, make the blade more intensive and more safe, with no clips that have a single spiral, both of which have very good protection effect, is a good choice.
Application
Blade barbed wire can be placed on top of the concrete wall. With two iron plates or other hard flaps, the nail can be passed through the flaps, the razor wire and the concrete wall to hold the three together. Or put it on top of the house to prevent climbing or standing birds, which are obviously visible day and night, and can act as a deterrent, reducing bleeding and injury.
Feature
The spiral cross blade barbed wire is a strong clip between the two blade barbed wire with stainless steel sheet and galvanized steel sheet. It will be cross-shaped when opened, beautiful and useful. Straight blade barbed wire, there are a variety of options for erection methods, sensitive construction, not only saves expenditure, but also can achieve the effect of deterrence.
Specifications
| Outside Dia. | No.of Loops | Standard Length per Coil | Typs | Notes |
| 300mm | 33 | 4-5m | CBT-60.65 | Single coil |
| 450mm | 33 | 7-8m | CBT-60.65 | Single coil |
| 500mm | 56 | 12-13m | CBT-60.65 | Single coil |
| 700mm | 56 | 13-14m | CBT-60.65 | Single coil |
| 960mm | 56 | 14-15m | CBT-60.65 | Single coil |
| 450mm | 56 | 8-9m(3 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 500mm | 56 | 9-10m(3 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 600mm | 56 | 10-11m(3 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 600mm | 56 | 8-10m(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 700mm | 56 | 10-12(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 800mm | 56 | 11-13m(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 900mm | 56 | 12-14m(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 960mm | 56 | 13-15m(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 980mm | 56 | 14-16m(5 clips) | BTO-10.12.18.22.28.30 |
| Specification | Thickness (mm) | Wire Dia. (mm) | Barb Length (mm) | Barb Width (mm) | Barb spacing (mm) |
| BTO-10 | 0.45±0.05 | 2.0-3.0 | 10±1 | 13±1 | 26±1 |
| BTO-12 | 0.45±0.05 | 2.0-3.0 | 12±1 | 15±1 | 26±1 |
| BTO-18 | 0.45±0.05 | 2.0-3.0 | 18±1 | 15±1 | 33±1 |
| BTO-22 | 0.45±0.05 | 2.0-3.0 | 22±1 | 15±1 | 34±1 |
| BTO-28 | 0.45±0.05 | 2.0-3.0 | 28±1 | 15±1 | 45±1 |
| BTO-30 | 0.45±0.05 | 2.0-3.0 | 30±1 | 18±1 | 45±1 |
| CBT-60 | 0.45±0.05 | 2.0-3.0 | 60±2 | 32±1 | 100±2 |
| CBT-65 | 0.45±0.05 | 2.0-3.0 | 65±2 | 21±1 | 100±2 |
| Type | Razor Mesh(Diamond Hole) | Razor Mesh(Square Hole) |
| Thickness of Sheet | 0.5mm±0.05mm | |
| Wire Diameter | 2.5mm±0.1mm | |
| Height | 1.0m-2.4m | |
| Length | 2.0m-10.0m | |
| Mesh Size | 75mmx150mm 100mmx200mm 150mmx300mm | 150mmx150mm 200mmx200mm 300mmx300mm |
Trade Terms
Trade terms: FOB, CNF, CIF,
Payment terms: 30%T/T as deposit , L/C, Western Union,
MOQ:20tons
Port: TIANJIN
Sample time: 1-3days
Lead time: 10days depend on the final order quantity
Shipment: By sea or airport
Supply capability:600tons/month
Popular size :
Razor wire single coil, CBT-65, 200 mm coil diameter, 33 loops, 8 m per coil.
Razor wire single coil, CBT-65, 200 mm coil diameter, 33 loops, 8 m per coil.
Galvanized razor barbed wire, BTO-22 or CBT-65, coil diameter 800 mm.
Razor wire, blade type: BTO-10, BTO-15, BTO-22, cross type, coil diameter: 700 mm.
Stainless steel 304 razor wire, BTO-30.
Razor wire BTO-22, outer roll size 18 and 24 inches.
Razor wire BTO 22, outer roll size 18 and 24 inches.
Stainless steel razor wire, 3 clips per coil, in 450 mm coils with blade style of BTO-22.
Stainless steel razor wire, BTO-30, cross type, 500 loops, 3 clips, length 10 m.
Razor edge wire 27 inch diameter single coil BTO-65.
