Fencing Use Spiral Razor Wire For Resident Safety Houses Knife Shaving Mesh
Spiral Razor Wire Information:
In general, the larger the razor concertina cross section, the larger the diameter of the spiral coil, the greater the staples used to bond the turns of the spiral razor fence and the less the length of the razor wire, the more efficient running spiral razor security barrier .
Using galvanized wire and galvanized staples fix the spiral razor wire fence.
Galvanized spiral razor wire to be installed in natural loops without clips, we can do the coil diameter from 200mm to 1050mm , on fence ,the most popular is 500mm coild diameter in 10kg /roll as below :
| Diameter of coil (lying horizontally) | 500mm |
| Steel wire thickness | 2.5 mm |
| Blade length | 22 mm |
| Blade thickness | 0.5 mm |
| Blade width (depth) | 10 mm |
| Clear distance between blades | 25 mm |
| length per roll |
10m or 15m is the standard |
Packing
1.LCL: packed waterproof paper + wroven bag , with plastic film then on the pallets
2.FCL: Nude packing
3.Other special package according to customers' requirements.
Payment Terms
T/T( 30% deposit , 70% balance against BL copy ), or L/C, Paypal, Western Union,MoneyGram, Credit Card
Other size as reference
| Outside Dia. | No.of Loops | Standard Length per Coil | Typs | Notes |
| 300mm | 33 | 4-5m | CBT-60.65 | Single coil |
| 450mm | 33 | 7-8m | CBT-60.65 | Single coil |
| 500mm | 56 | 12-13m | CBT-60.65 | Single coil |
| 700mm | 56 | 13-14m | CBT-60.65 | Single coil |
| 960mm | 56 | 14-15m | CBT-60.65 | Single coil |
| 450mm | 56 | 8-9m(3 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 500mm | 56 | 9-10m(3 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 600mm | 56 | 10-11m(3 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 600mm | 56 | 8-10m(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 700mm | 56 | 10-12(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 800mm | 56 | 11-13m(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 900mm | 56 | 12-14m(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 960mm | 56 | 13-15m(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 980mm | 56 | 14-16m(5 clips) | BTO-10.12.18.22.28.30 |
| Specification |
Thickness (mm)
|
Wire Dia. (mm)
|
Barb Length (mm)
|
Barb Width (mm)
|
Barb spacing (mm)
|
| BTO-10 | 0.45±0.05 | 2.0-3.0 | 10±1 | 13±1 | 26±1 |
| BTO-12 | 0.45±0.05 | 2.0-3.0 | 12±1 | 15±1 | 26±1 |
| BTO-18 | 0.45±0.05 | 2.0-3.0 | 18±1 | 15±1 | 33±1 |
| BTO-22 | 0.45±0.05 | 2.0-3.0 | 22±1 | 15±1 | 34±1 |
| BTO-28 | 0.45±0.05 | 2.0-3.0 | 28±1 | 15±1 | 45±1 |
| BTO-30 | 0.45±0.05 | 2.0-3.0 | 30±1 | 18±1 | 45±1 |
| CBT-60 | 0.45±0.05 | 2.0-3.0 | 60±2 | 32±1 | 100±2 |
| CBT-65 | 0.45±0.05 | 2.0-3.0 | 65±2 | 21±1 | 100±2 |
SAMPLE IS FREE AND READY WITHIN 1-3 DAYS
Sample time: 1-3days
Lead time: 10days depend on the final order quantity
Shipment: By sea or airport
Supply capability:600tons/month
