High quality China factory automatic vertical plastic round bottle labeling machine labeling machin bottl for drink/wine/oil

Automatic vertical bottle labeling machine

Equipment Overview:

Fully-automatic self-adhesive vertical round bottle labeling machine is widely used for the labeling of circumferential surface objects of various specifications, and taper round bottle labeling, such as cosmetics, food, medicine, daily chemicals, toys, hardware, plastics, etc. Such as drink bottles, wine bottles, sauce bottles, oil bottles, can realize the full round/half round labeling, double labeling on the front and back of the circle, and the from-to-back mark spacing can be arbitrarily adjusted.

Technical Parameters:

Label specification: length 15mm~290mm; width 15mm~150mm

Product Specifications: Φ25mm~90mm;

Product height: 25~300mm

The outside diameter of the label: Φ280mm;

Roll diameter: Φ76mm

Labeling speed: 10~100 bottles/minute

Labeling accuracy: ±1mm

Air pressure: 0.6~0.8Mpa

Power: 850w (step), 1150w (servo)

Voltage: 220V 50Hz
