Hot Selling Good Quality of Guanhong Amchinery Pipe Sticking Machine Lubricant Labeling Machine Tube Sticker

Hot Selling Good Quality of Guanhong Amchinery Pipe Sticking Machine Lubricant Labeling Machine Tube Sticker photo-1
Hot Selling Good Quality of Guanhong Amchinery Pipe Sticking Machine Lubricant Labeling Machine Tube Sticker photo-2
Hot Selling Good Quality of Guanhong Amchinery Pipe Sticking Machine Lubricant Labeling Machine Tube Sticker photo-3
Hot Selling Good Quality of Guanhong Amchinery Pipe Sticking Machine Lubricant Labeling Machine Tube Sticker photo-4
Hot Selling Good Quality of Guanhong Amchinery Pipe Sticking Machine Lubricant Labeling Machine Tube Sticker photo-5
US$ 60000 - 70000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Guanhong Intelligent
Place of Origin:
China
Model Number:
15217238829
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
30 days
Brand Name Guanhong Intelligent
Place of Origin China
Model Number 15217238829
Certification http://gd-guanhong.com/
After-sales Service Provided Engineers available to service machinery overseas
Weight 280KG
Dimension(L*W*H) 2000mm*1500mm*2000mm
Voltage AC220V/380V 50/60Hz
Power about 1.5KW
Application Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical
Condition New
Automatic Grade Automatic
Driven Type Electric
Packaging Material Glass, Metal, Plastic




Automatic sticking tube machine

Equipment Overview:

This machine is used for bottle sticking tube. Using PLC microcomputer human-machine interface operation, the program is practical and simple. Its equipment can automatically setting the location of the paste, high precision, large output, a large number of saving labor, increase production efficiency, improve product quality. Such as: aerosols, lubricants, rust inhibitors and other cans/ tin products.


Technical Parameters:

1. Applicable product range: diameter 67+/-2mm, height 150-220

(Other round container diameters or heights need to replace the bottle turntable and adjust the machine).

2. Size of adhesive tape: height 15-25, length 15-35 (transparent tape, paper tape).

(Transparent tape labels need to be printed on the label or the base paper)

3. Applicable tube size: According to customer's sample

4. Sticking tube error: positioning paste mode, height direction ± 2mm, axial direction ± 2mm.

5. Labeling error: ±2mm

6. Production capacity: 45~50 bottles/minute

7. The height of the conveyor belt from the ground: 800±20mm.

8. Rated voltage: 220V/50Hz.

9. Overall power: 1.5KW.

10. Working pressure: 0.5-0.7Mpa.


Product Tags: automatic sticking machine , tube sticker , lubricant pipe stick machine
