Double heads tracking type servo torsion capping machine Equipment Overview：
Double heads tracking type servo torsion capping machine consist of chain conveyor, composed of bottle clamp automatic alignment mechanism, screw capping system, the automatic servo tracking system, servo torque screw capping system, electric lift regulating mechanism, electric cap sorting and cap feeding, waterproof electrical cabinets, touch screen human-machine interface, etc., this machine is a key to quickly switch in bottle function, can apply to different specifications automatic multiple-function equipment of the bottle.
Technical
Filling heads: 2 heads
2.Filling capacity: 500-5000ml
3.Filing form: double head servo tracking type filig
4.illing speed: about 40-50 bttles/min (Based on 500ml bottle, actuallydepends on bottle cap size and material)
5,Filling accuracy: ±1%
6.Material: The flling machine frame is 304# stainless steel
7.Program control: Cotrust motion control system (motion control bus,touch screen, etc.)
8.Filling nozzle, feed tank and other liquid contact parts material: 304#stainless steel, food grade PVC
9.Air pressure: 0.6-0.8 MPa
10,Conveyor belt : 82mm wide POM chain belt, speed 0- 15m/min, height850mm+ 25mm off the ground
11.Conveyor motor: 370W frequency control motor
12.Power: about 2kW /AC220V/380V 50/60Hz
