SS 304 Stainless Steel Wire Diamond Mesh Security Window Screen
US$ 4.5 - 4.8
MOQ: 50 Square Meters
Key Specifications
Get Latest Price
Brand Name:
FuHua
Place of Origin:
China
Model Number:
Stainless Steel Wire Mesh
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
AISI304 or AISI316 Grade Stainless Steel Wire Mesh for Aluminum Alloy Screen Doors and WindowsUS$ 20 - 25MOQ: 100 Square Meters -
Stainless Steel Window Screen Black Powder Coated Stainless Steel Insect Screen for Aluminum Windows and DoorsUS$ 4.6 - 4.8MOQ: 100 Square Meters
-
Black Powder Coated Stainless Steel Woven Wire Mesh Used as Insect Screen for Aluminum Windows and DoorsUS$ 4.6 - 4.8MOQ: 100 Square Meters
-
Black Stainless Steel Insect Screen PVC Coated Stainless Steel Fly Screen for Aluminum Doors and WindowsUS$ 4.6 - 4.8MOQ: 100 Square Meters
-
Powder Coated Black Woven Stainless Steel Wire Mesh for Insect Screen Aluminum Doors and WindowsUS$ 4.6 - 4.8MOQ: 100 Square Meters
Brand Name
FuHua
Place of Origin
China
Model Number
Stainless Steel Wire Mesh
Material
Stainless Steel Wire
Type
Other, Woven Mesh
Application
Other, Window Screen
Technique
Woven
Wire Diameter
0.6-0.9mm
Weave Style
Plain Weave
SS 304 Stainless Steel Wire Diamond Mesh Security Window Screen
Introduction:
Diamond wire mesh is a high-strength metal mesh woven with 304 or 316 stainless steel wire, which has been color powder coated to obtain a delicate appearance. Its own material determines that it has excellent rust and corrosion resistance, high strength, suitable for building mosquito prevention, anti-theft and decoration and other occasions.Material:
304 stainless steel wire: American standard 304 stainless steel wire, corresponding to the national standard 06Cr19Ni10 (old brand 0Cr18Ni9), general purpose stainless steel wire, diamond mesh window screen using a wide range of materials.316 stainless steel wire: American standard 316 stainless steel wire, corresponding to the national standard 06Cr17Ni12Mo2 (old brand 0Cr17Ni12Mo2), applicable to seawater and other strong corrosive environment pitting resistant materials, special industrial corrosive environment diamond mesh window screen selection.
Process:
Diamond mesh window screen adopts heavy-duty dense weaving process, tensile strength reaches 650N/mm2~750N/mm2, with high strength and light weight aluminum profiles to make the screen door and window with strong resistance to external damage; mesh number 10-14 range, mosquitoes shall not pass through in summer, accompanying you a good sleep.
Specifications:
The standard specification series of stainless steel wire diamond mesh window screens are:1、FH-CS-SS-0.9/10: wire diameter 0.9mm, mesh number 10, aperture 1.64mm.
2、FH-CS-SS-0.8/11: wire diameter 0.8mm, mesh number 11, aperture 1.50mm.
3、FH-CS-SS-0.7/12：filament diameter 0.7mm, mesh number 12, aperture 1.41mm.
4、Stock standing mesh roll width 0.8m, 1.0m, 1.2m, 1.5m, length 30m, 50m, 100m.
5、Standard electrostatic spraying room, the average thickness of the coating range 0.05mm ~ 0.10mm. black, dark gray paint is always available, other colors need to be customized by the user to provide color plates.
