The new crown epidemic is a global challenge for human beings, and in order to effectively control the spread of the epidemic, regional isolation control of different countries and regions is an effective means of epidemic containment. The border line of neighboring countries is a difficult area to control the cross-border movement of people, in order to quickly achieve the purpose of isolating the cross-border movement of people in the border area, the installation of razor barbed wire near the border line is a simple and effective measure.
Advantages of razor barbed wire.1. simple structure form, easy to make, suitable for mass processing and production and use.
2. It can effectively play the role of isolation and protection, with obvious functional effect. Widely used in border line, border guard post, prison, railroad and other areas with common and high security requirements.
3. It is an economic isolation and protection facility due to the wide source of materials used, low cost and cheap price.
4. A variety of standard specifications are available, and special specifications can be customized on demand, and custom processing is easy.
Materials and corrosion protection of razor wire.1. The materials used in razor wire include: fine steel wire and thin steel plate.
2. Steel wire materials include: electro galvanized wire, hot dip galvanized wire, 304 stainless steel wire.
3. Steel plate material: galvanized plate, 304 stainless steel plate. 4.
4. Anti-corrosion performance: 304 stainless steel material has better rust resistance than galvanized material, and the cost is higher. Hot-dip galvanized material is generally higher than galvanized material zinc layer thickness, corrosion resistance is also good, which also depends on the value of the respective amount of zinc.
Commonly marked razor wire mesh models and data are as follows.Barb Specifications of Razor Barbed Wire | |||||
Model |
Thickness |
Wire Diameter |
Barb Length |
Barb Width |
Barb Spacing |
BTO-10 |
0.5 ± 0.05 |
2.5 ± 0.1 |
10 ± 1 |
13 ± 1 |
26 ± 1 |
BTO-12 |
0.5 ± 0.05 |
2.5 ± 0.1 |
12 ± 1 |
15 ± 1 |
26 ± 1 |
BTO-18 |
0.5 ± 0.05 |
2.5 ± 0.1 |
18 ± 1 |
15 ± 1 |
35 ± 1 |
BTO-22 |
0.5 ± 0.05 |
2.5 ± 0.1 |
22 ± 1 |
15 ± 1 |
35 ± 1 |
BTO-28 |
0.5 ± 0.05 |
2.5 ± 0.1 |
28 ± 1 |
15 ± 1 |
53 ± 1 |
BTO-30 |
0.5 ± 0.05 |
2.5 ± 0.1 |
30 ± 1 |
21 ± 1 |
54 ± 1 |
CBT-60 |
0.6 ± 0.05 |
2.5 ± 0.1 |
60 ± 2 |
32 ± 1 |
102 ± 1 |
CBT-65 |
0.6 ± 0.05 |
2.5 ± 0.1 |
65 ± 2 |
21 ± 1 |
102 ± 1 |
Coil Specifications of Razor Barbed Wire | ||||
Coil Diameter |
Loops |
Deployed Length |
Barb Moder |
Note |
450mm |
33 |
7-8 M |
CBT-60.65 |
Single Coil |
500mm |
56 |
12-13M |
CBT-60.65 |
Single Coil |
700mm |
56 |
13-14M |
CBT-60.65 |
Single Coil |
960mm |
56 |
14-15M |
CBT-60.65 |
Single Coil |
450mm |
56 |
8-9 M (3 Clips) |
BTO-10.12.18.22.28.30 |
Cross Type |
500mm |
56 |
9-10 M (3 Clips) |
BTO-10.12.18.22.28.30 |
Cross Type |
600mm |
56 |
10-11M (3 Clips) |
BTO-10.12.18.22.28.30 |
Cross Type |
600mm |
56 |
8-10 M (5 Clips) |
BTO-10.12.18.22.28.30 |
Cross Type |
700mm |
56 |
10-12M (5 Clips) |
BTO-10.12.18.22.28.30 |
Cross Type |
800mm |
56 |
11-13M (5 Clips) |
BTO-10.12.18.22.28.30 |
Cross Type |
900mm |
56 |
12-14M (5 Clips) |
BTO-10.12.18.22.28.30 |
Cross Type |
960mm |
56 |
13-15M (5 Clips) |
BTO-10.12.18.22.28.30 |
Cross Type |
980mm |
56 |
14-16M (5 Clips) |
BTO-10.12.18.22.28.30 |
Cross Type |
1. Material. (galvanized material, stainless steel material. (In case of galvanized material, the amount of zinc required.
2. type of spike. (Diameter of steel wire, thickness of steel plate, spacing of spikes.
3. the parameters of the mesh ring. (The diameter of the mesh ring, the number of turns per roll or the installation length.
