Home > Industrial Equipment & Components > Pump & Vacuum Equipment > Water Pump > 6v 12v 24v dc Mini Micro Air Pump Diaphragm Pump

6v 12v 24v dc Mini Micro Air Pump Diaphragm Pump

Name: 6v 12v 24v dc Mini Micro Air Pump Diaphragm Pump
Brand: topsflo
SKU: 167911647
Availability: InStock

TOPS Industry & Technology Co., Ltd.

6v 12v 24v dc Mini Micro Air Pump Diaphragm Pump thumbnail-1

6v 12v 24v dc Mini Micro Air Pump Diaphragm Pump thumbnail-2

6v 12v 24v dc Mini Micro Air Pump Diaphragm Pump photo-1

6v 12v 24v dc Mini Micro Air Pump Diaphragm Pump photo-2

Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

topsflo

Place of Origin:

China

Model Number:

TM30A-A

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name topsflo

Place of Origin China

Model Number TM30A-A

Application Other, vacuum / pressure applications, Gas transferring and evacuating

Power Electric

Usage Water

Theory Vacuum Pump

Standard or Nonstandard Standard

Structure Diaphragm Pump

Pressure High Pressure

Why choose TOPSFLO Factory ?

♦ TOPSFLO is the only double certified enterprise by German TUV IATF16949 & ISO9001 in the pump industry

♦  16 years of industry experience.Independent research and development, national high-tech enterprise, multiple domestic and foreign invention patents
♦  Annual production capacity of 3,008,000 pieces
♦  4 laboratories that meeting the CNAS certification standard
♦  80% of the products are exported to high-end market in Europe and America

Remarks:
- We are high-end Brushless DC pumps Manufacturer. Can provide customized services
- If you are interested in our products, pls feel free to contact us

Customer Reviews

Company Information

Product Description

6v 12v 24v dc mini micro air pump

Product Specification

Model	TM30A-A	TM30A-B	TM30A-C	TM30A-D
Motor type	A--high performance Brush motor	B--Brush motor	C--Brushless motor	D--Brushless motor
Pump Assembly Rated Life	3000hour	1000hour	15000hour	15000hour
Gas flow	6L/min	4.5L/min	4.5L/min	4L/min
Rated Voltage	12V	6/12/24v	6/12/24v	6/12/24v
No-load Current	0.24A	0.4/0.24/0.15A
Media	Most gas
Max Pressure	120kpa
Max Vacuum	-70kpa
Ambient Temperature	41 to 158 F(5 to 70C)
Pump size	75.530.454.6mm	7531.257.5mm	7931.257.5mm	7931.257.5mm
Weight	200g	150g	250g	250g
Inlet&Outlet	OD 4.8mm/ID 2.6mm,hose suggestion:ID 4.0mm
Materials	pump head Nylon, membrane EPDM , valve EPDM	pump head Nylon, membrane EPDM / PTFE, valve EPDM / FPM	pump head Nylon, membrane EPDM / PTFE, valve EPDM / FPM	pump head Nylon, membrane EPDM / PTFE, valve EPDM / FPM
Wetted material options	1.Optional membrane materials: EPDM for normal air PTFE for corrosive air,like acid, alkali air, ozone etc. 2.Optional valve materials: EPDM for normal air FPM for corrosive air, like acid, alkali, ozone,etc.

TOPSFLO Diaphragm series gas pumps are the perfect combination of form and function. The use of a special diaphragm allows the pump to transfer both air and liquid efficiently. The compact lightweight unit offers optimum sizing for analytical equipment.

ADVANTAGES

♦ High pneumatic performance
♦ Compact size/high power density
♦ Uncontaminated flow – no contamination of the media due to oil-free operation
♦ Maintenance-free
♦ Long product life

♦ Low sound level

♦ Low power consumption
♦ Can operate in any orientation

♦ Suction

APPLICATION

1. Industrial pressure and vacuum applications 2. Portable Analytical Instruments 3. Medical Diagnostic Equipment
4. Air Quality Sampling Monitors 5. Respiration Monitors 6. Gas or Odor Leak Detectors etc..

Performance Curve

More About Products

Model	Product Name
TM30A-A	Brush small air pump/vacuum pump
TM30A-B	Brush small air pump/vacuum pump
TM30A-C	Brushless small air pump/vacuum pump
TM30A-D	Brushless small air pump/vacuum pump
TM30B-A	Brush small air pump/vacuum pump
TM30B-C/D	Brushless small air pump/vacuum pump
TM30B-H	Brushless small air pump/vacuum pump
TM40A-A	High pressure /vacuum brush air pump
TM40A-B	High pressure /vacuum brush air pump
TM40A-C	High pressure /vacuum brushless air pump
TM40A-E/F	High pressure /vacuum brushless air pump
TMD40A-F	High pressure /vacuum brushless air pump
TMD40A-A	High pressure /vacuum brush air pump
TMD45A-A	High pressure /vacuum brush air pump
