Product Overview
XY-BT-288 N Fold Hand Towel Paper Making Machine Price
Outline
This machine is used for embossing and cutting off the towel paper. The folding of products is “V” type folding and you can draw it one by one. This kind of towel paper is used widely in hotel, office and kitchen etc, which is convenient and sanitation. We adopt original creation full vacuum absorption technology, the adaptability of raw material is so strong. This machine is for folding, slitting and counting with high speed and output orderliness.
Video Link: https://youtu.be/BdCu4WzT2K4
This machine is used for embossing and cutting off the towel paper. The folding of products is “V” type folding and you can draw it one by one. This kind of towel paper is used widely in hotel, office and kitchen etc, which is convenient and sanitation. We adopt original creation full vacuum absorption technology, the adaptability of raw material is so strong. This machine is for folding, slitting and counting with high speed and output orderliness.
Video Link: https://youtu.be/BdCu4WzT2K4
Function & Features
1. Production speed :（60~100）m/min
2. Embossing unit: Steel to steel embossing unit.
3. Pneumatic broken paper automatic separation, convenient wear paper.
4. Using synchronous belt transmission, transmission ratio is accurate, low noise.
5. Base paper adapt range: 33-45g/m2 (single ply)
6. To be order two layers glue lamination.(Optional)
Details Images
Product Paramenters
Product capacity | 900 sheets/line/minute |
Jumbo roll size | 460-1380mm(W)*1200mm(D) |
Unfolding size (L*W) | 210mm (L)*210mm(W) |
Folded size (L*W) | 105mm (L)*210mm(W) |
Controlling system | Frequency drive |
Counter | Ink marked |
Embossing unit | Steel to steel embossing rollers |
Power | 7.5-35KW 380V 50HZ 3Phase |
Overall size | Depend on model |
Weight | 2000-6000KG |
Jumbo roll material qualify | Basic Weight:33-45 gsm/1 ply 14-20 gsm/2 ply Jumbo Roll Paper Core: 3 inches |
Remark | This machine can be customized to work with one set of glue lamination system |
Related Products
Workshop
Packing & Delivery
Company Profile
Fujian Xinyun Machinery Development Co.,Ltd is good at Paper Converting Machinery Manufacture.Professional supplier of:
1) Toilet Paper Machine (1.2m--2.8m width of parent roll, Customize Service)
2) Roll Kitchen Paper Towel Machine (1.2m--2.8m width of parent roll, Customize Service)
3) Facial Tissue Machine (2-14 output lanes)
4 )Napkin Paper machine(L-fold, 1/4-fold, 1/6-fold, 1/8-fold and other multi-fold type)
5) Hand Towel Paper Machine(C-fold, V-fold and N/Z fold type)
6) Pocket Tissue Machine(mini and standard size)
7) All kinds of Tissue Paper Cutting and Packing Machine
8) Another Household Paper Equipments and Production Line.
