Home > Instruments & Meters > Test Instrument > Test Machine > Beifang 12PSB-BFB Diesel Pump Test Equipment Pump Common Rail Tester
Beifang 12PSB-BFB Diesel Pump Test Equipment Pump Common Rail Tester
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
1998
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Beifang Brand High Quality EPS100 Common Rail Injectors Detector Common Rail Injectors Test BenchNegotiableMOQ: 1 -
BF198 Expert High Pressure Injector Common Rail Test Bench Diesel Pump Bench Test Diagnostic Machine for All CarsNegotiableMOQ: 1
-
China Famous Brand Beifang PQ1000 Common Rail Diesel Fuel Injector Test Bench With Small ScreenNegotiableMOQ: 1
-
China Famous Brand Beifang BF1176 Diesel Fuel Common Rail Injector Test BenchNegotiableMOQ: 1
-
China Famous Brand Beifang CR-C Common Rail Injector TesterNegotiableMOQ: 1
Beifang 12PSB-BFB auto services pump calibration machine
Product Description
Beifang BFB crdi pump injector tester is our best seller model, which used to test mechanical pumps, like inline pumps, distributor pumps, for example :Ⅰ, Ⅱ, Ⅲ, A, B, P, VE, OW, PL, BQ, Z, P7, PW, PN, PB, P2000, PS7100, EP9, PS8500, P8000, MW etc, kinds of domestic and oerseas pumps. It adopts CRT screen display and LED digital display two control system, can perform various function's adjusting and testing to the injection pump.
Technical Parameters
Beifang 12PSB-BFB auto services pump calibration machine |
||
Name |
BFB diesel fuel injection pump test bench |
|
Main motor power |
15kw |
|
Host machine source |
380V/50-60HZ 3Phase(220V/50-60HZ 1Phase,220V/50-60HZ 3Phase) |
|
Test bench rotated speed |
0-4000 rpm/min |
|
Oil supply |
10L/min , 20L/min |
|
Oil supply high pressure |
0-3.5Mpa |
|
Oil supply low pressure |
0-0.35Mpa |
|
Air supply pressure range |
0-0.18Mpa |
|
DC power |
12V or 24V(Allow short circuit) |
|
Shaft centre height |
125 MM |
|
Test bench height from the ground |
830 MM |
|
Oil tank capacity |
50 L |
|
Fuel oil temperature |
40±2℃ |
|
Overall size(mm) |
2150*750*1850 |
|
Weight(kg) |
950 |
|
Features&Function
Features
1.Three styles, two language screen interface for thee operator to choose.2.The main motor frequency control, manual and automatic two modes of operation.
3.12V, 24V DC power supply for solenoid calve drive and detection.
4.The test oil temperature automatic control, can reduce the temperatire on the amount of oil precision.
5.Automatic mode can be multi-speed preset speed. Low noise,high pressure supply system.
Function
1.Test the speed of each cylinder under the oil supply;
2.Statically check the fuel tank time;
3.Check mechanical governor performance;
4.Distribute pump solenoid valve test;
5.The injection pump sealing test;
6.Measurement distribution pump body pressure, return pressure;
7.Check the pressure compensator performance;
8.Check the pneumatic governor performance;
9.Check the air film governor negative pressure performance.
2.Statically check the fuel tank time;
3.Check mechanical governor performance;
4.Distribute pump solenoid valve test;
5.The injection pump sealing test;
6.Measurement distribution pump body pressure, return pressure;
7.Check the pressure compensator performance;
8.Check the pneumatic governor performance;
9.Check the air film governor negative pressure performance.
Company Introduction
Packing&Shipping
Our Advantages
FAQ
1.Are you a manufacturer or trade company?
We are direct manufacturer with more than 10 years experience
2.What certification do you have ?
We have CE, ISO SGS Certification etc
3.How about the delivery time?
10 days after getting deposit
4.Do you also sell related accessories and repair tools?
Yes, except test bench,we also produce spare parts and repair or measuring tools, also offer factory price for you
5.Do you have foreign agent ?
Sure, we have built some several agents in the world and you can also be our agent.
We are direct manufacturer with more than 10 years experience
2.What certification do you have ?
We have CE, ISO SGS Certification etc
3.How about the delivery time?
10 days after getting deposit
4.Do you also sell related accessories and repair tools?
Yes, except test bench,we also produce spare parts and repair or measuring tools, also offer factory price for you
5.Do you have foreign agent ?
Sure, we have built some several agents in the world and you can also be our agent.
