Product introduction:
Flange Y-type strainer
Y-type filter is a indispensable device in transmission pipeline system, usually installed inlet in pressure reducing valve, pressure relief valve, water valve and other device, the valve is used to remove impurities in order to protect the valve and equipment in normal use.
Product Advantage:
Size:1/2"--18"
Material: cast iron,WCB,stainless steel 304(CF8)
Pressure: Class 150
Connection:Flange
Temperature range: ≤250℃
Applicable Media:water,oil
Adoptive Standards
Valve Design: DIN3352
Face To Face: DIN3202, BS2080
Flange Drilling: DIN2531/2/3, BS4504
Product Feature:
1,Strainer body meets applicable DIN standard,large inner space,reduce pressure drop.
2,Ductile iron body material,can't broken by transfer and install.
3,Streamline design for low pressure drop.
4,Epoxy coating,prevent corrosion and rust
5,There is pressure tap leave on the bonnet,can install pressure measuring device to test pipe pressure
| Name | 1-Body | 2-Strainer screen | 3-O ring | 4-Bonnet | 5-Plug | ||||
| Material | QT450 | 201/304 | EPDM | QT450 | QT450 | ||||
| SIZE | DN | D | D1 | D2 | L | b | f | Z-d | H |
| 1/2" | Φ15 | Φ95 | Φ65 | Φ46 | 130 | 14 | 2 | 4-Φ14 | 93 |
| 3/4" | Φ20 | Φ105 | Φ75 | Φ56 | 150 | 16 | 2 | 4-Φ14 | 103 |
| 1" | Φ25 | Φ115 | Φ85 | Φ65 | 160 | 16 | 3 | 4-Φ14 | 114 |
| 1 1/4" | Φ32 | Φ140 | Φ100 | Φ76 | 180 | 18 | 3 | 4-Φ19 | 132 |
| 1 1/2" | Φ40 | Φ150 | Φ110 | Φ84 | 200 | 18 | 3 | 4-Φ19 | 152 |
| 2" | Φ50 | Φ165 | Φ125 | Φ99 | 230 | 20 | 3 | 4-Φ19 | 154 |
| 2 1/2" | Φ65 | Φ185 | Φ145 | Φ118 | 290 | 20 | 3 | 4-Φ19 | 173 |
| 3" | Φ80 | Φ200 | Φ160 | Φ132 | 310 | 22 | 3 | 8-Φ19 | 195 |
| 4" | Φ100 | Φ220 | Φ180 | Φ156 | 350 | 24 | 3 | 8-Φ19 | 225 |
| 5" | Φ125 | Φ250 | Φ210 | Φ184 | 400 | 26 | 3 | 8-Φ19 | 268 |
| 6" | Φ150 | Φ285 | Φ240 | Φ211 | 480 | 26 | 3 | 8-Φ23 | 328 |
| 8" | Φ200 | Φ340 | Φ295 | Φ266 | 600 | 30 | 3 | 12-Φ23 | 425 |
| 10" | Φ250 | Φ405 | Φ355 | Φ319 | 730 | 32 | 3 | 12-Φ28 | 497 |
| 12" | Φ300 | Φ460 | Φ410 | Φ370 | 850 | 32 | 4 | 12-Φ28 | 564 |
| 14" | Φ350 | Φ520 | Φ470 | Φ429 | 980 | 36 | 4 | 16-Φ28 | 636 |
| 16" | Φ400 | Φ580 | Φ525 | Φ480 | 1100 | 38 | 4 | 16-Φ31 | 719 |
| 18" | Φ450 | Φ640 | Φ585 | Φ548 | 1200 | 40 | 4 | 20-Φ31 | 800 |
