Copper Conductor Twin Wire Parallel Electrical Wire
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2001
Annual Export Value:
US$1.5 Million - US$2.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sale TRI-RATED SUPER FLEXIBLE APPLIANCE CABLENegotiableMOQ: 1 -
Multiconductor Cable H05VV-F CABLE Flexible CablesNegotiableMOQ: 1
-
Best Price 1mm SDI Cable --red BlackNegotiableMOQ: 1
-
Pay Later IEC 60245 57 (YZW) 3x1.5sqmm 300/500V Rubber Insulation Flexible CableNegotiableMOQ: 1
-
Pay Later PV Cable Solar Cable Single Core 6mm for Solar Power SystemNegotiableMOQ: 1
Flexible twin wire parallel electrical wire
Twin Parallel Flexible Wire
1. Standard: 60227 IEC42
2. Voltage: 300/500V and 450/750V
3. Package: Wrapped PE Coil; Shrinked Polybag Coil; Carton Box; Carton Reel; Wooden Reel, etc.
60227 IEC42 (BVVR) 300/500V & 450/750V Stranded flexible copper conductor PVC insulated PVC sheathed parallel wire (twin)
| Cores | Conductor | Insulation | Jacket | Max. Resistance at 20(Ω/km) | Approx Weight kg/km | |||
| Section/mm2 | Structure/mm | Nom.Thickness/mm | Nom. Dia./mm | Nom. Thickness | Nom. Dia./mm | |||
| 2 | 0.75 | 1/0.97 | 0.6 | 2.23 | 0.9 | 4.13x6.45 | 24.5 | 42 |
| 2 | 1 | 1/1.13 | 0.6 | 2.4 | 0.9 | 4.29x6.78 | 18.1 | 49 |
| 2 | 1.5 | 1/1.38 | 0.7 | 2.86 | 0.9 | 4.75x7.73 | 12.1 | 65 |
| 2 | 2.5 | 1/1.78 | 0.8 | 3.47 | 1 | 5.57x9.05 | 7.41 | 97 |
| 2 | 4 | 1/2.25 | 0.8 | 3.95 | 1 | 6.05x10.0 | 4.61 | 132 |
| 2 | 6 | 1/2.76 | 0.8 | 4.46 | 1.1 | 6.71x11.24 | 3.08 | 180 |
| 2 | 10 | 7/1.35 | 1 | 6.35 | 1.2 | 8.87x15.23 | 1.83 | 303 |
| 3 | 0.75 | 1/0.97 | 0.6 | 2.23 | 0.9 | 4.13x8.61 | 24.5 | 60 |
| 3 | 1 | 1/1.13 | 0.6 | 2.4 | 0.9 | 4.23x8.91 | 18.1 | 71 |
| 3 | 4 | 1/2.25 | 0.8 | 3.95 | 1.1 | 6.05x13.91 | 4.61 | 199 |
| 3 | 6 | 1/2.76 | 0.8 | 4.46 | 1.1 | 6.71x15.71 | 3.08 | 267 |
| 3 | 10 | 7/1.35 | 1 | 6.36 | 1.2 | 8.87x21.57 | 1.83 | 451 |
