Flexible 6/10kv mining cable protolon reclaimer power reeling cable

Flexible 6/10kv mining cable protolon reclaimer power reeling cable

Application:

Application range:

Trailing cables are mainly used in industrial electronic systems, automatic generation lines, warehousing equipment, robots, fire fighting systems, cranes, CNC machine tools and metallurgical industry. When equipment units need to move back and forth, in order to prevent cable entanglement, abrasion, pull-off, hanging and scattering, cables are often placed in cable tow chains to protect the cables, and the cables can also move back and forth with the tow chains.

Trial in dry or wet rooms, without the installation of free continuous reciprocating motion with strong stress relief or forced guidance, especially in frequent reciprocating motions in industrial environments, such as woodworking machinery, machine tool processing equipment, logistics conveyor systems, crane applications and so on.



Shielding, PVC insulation, digital identification core wire, PVC inner and outer sheath, proven to be reliable, economical solution

information

Core products in power towline applications

Meets electromagnetic interference requirements

Application range

For power tow chains or moving mechanical parts

For measuring, controlling and regulating circuits

Power circuit in automation engineering electrical equipment

Assembly line, production line, all machines

Equipment installation engineering



Cable structure

Ultra-thin bare copper wire stranded conductor (6 types)

Core insulation: PVC

The core wire is twisted with a short pitch

PVC inner sheath, grey

Tinned copper braided shield

Non-woven wrapping

PVC outer sheath, grey (RAL 7001)



Technical certification

Core wire based on VDE 0245 / 0285

Outer sheath in accordance with VDE 0245/0285

Transmission distance ≤ 10 m

Product Features

Low viscosity surface

Flame retardant in accordance with IEC 60332-1-2

For wet indoors

Designed for bending cycles up to 2-8 million times in a power chain

Can be used outdoors only in the specified temperature range, UV protection

*Above specifications can be adjusted to customers' needs.
