Adhesive Label Temperature Control Lasting Adhesive Tester is suitable for the lasting adhesion of various pressure-sensitive tapes, medical tapes, adhesive tapes, labels and other products at different temperatures.
FeaturesØ Micro-computer controls process. Touch interface is more convenient to operate.
Ø Test plate and weight-counters designed strictly in accordance with the standard are to ensure the accuracy of data.
Ø Multiple items can be processed synchronously in six stations.
Ø High-precise control and self-calibration of P.I.D temperature system lead to get accurate test results.
Ø Independent EGO system protects from emergencies (power-off, over-temperature, over-load).
Ø Mirror plate is made by stainless steel according to national standard and pharmacopoeia.
PrincipleThis instrument is used for adhesion test at high temperature. Test the resistance of the adhesive tape attached on the test plate under the specified gravity along the length at the settable temperature. Calculating adhesion is based on the time when the test piece moves for a certain distance (or completely falls off) or the distance of displacement within a certain time (or completely falls off).
StandardsYY\T0148, GB/T 4851, ASTM D3654, JIS Z0237
ApplicationsVarious adhesives, e.g, pressure-sensitive tapes, medical patches, adhesive labels and protection films.
Technical SpecificationsTemperature |
Room temperature ~ 100℃ |
Size of Test Plate |
200 mm (L) × 50 mm (W) × 1.5 mm (D) |
Optional: 125mm (L) × 50mm (W)× 1.5mm (D) | |
Accuracy of Control |
±0.1 ℃ |
Distributing accuracy |
±1% (1℃) |
Weight-counter |
200g, 500g, 1000g (Include triangle hook) |
Timer |
≥10000 h |
Number of Stations |
6 |
Dimension |
760 mm (L) × 260 mm (W) × 720 mm (H) |
Instrument, Micro-Printer, Triangle Hook, Test Plate, Standard Roller.
