Help CenterSimple and Convenient Incline Impact Tester for Product Packaging
Related Products
The KRD100 series incline impact tester simulates the ability of product packaging to resist shock damage in the actual environment, such as handling, stacking of shelves, sliding of motors, loading and unloading of locomotives, product transportation, etc. This machine can also be used as a common test equipment for scientific research institutions, colleges and universities, packaging technology test centers, packaging materials manufacturing plants, and foreign trade, transportation and other departments to conduct incline impact test. In the modern logistics and packaging industry, product packaging is frequently subjected to horizontal impact forces during handling, stacking, loading, unloading, and transit. Evaluating packaging durability under such conditions is critical to ensuring product integrity and supply chain efficiency. The KRD100 series is widely applied in packaging material manufacturing, e-commerce and express delivery, logistics services, scientific research, higher education institutions, foreign trade, and commodity inspection sectors. The KRD100 series complies with ISTA 1/2/3/6 Series, ISO 2244 and ASTM D880-92.
l Flexible low-damping tackle, high repetition accuracy, to achieve the required speed change value.
l High-strength and low-friction profile guide rails are beneficial to the accurate free sliding of the block.
l For heavy-duty test products, the horizontal rotation mechanism of the composite pulley table can be added to facilitate the user to install the test pieces.
l Hard wooden or iron sliding table, effectively protect the surface of the test piece.
l Complete control and measurement system, simple and convenient operation, integrated control and measurement.
l Unique lifting and release methods, with obvious advancement and reliability.
l During installation, the customer only needs to fix the machine on the ground, without other complicated operations or installation.
Technical Specifications
|
Parameters |
KRD100－100 |
KRD100－200 |
KRD100－300 |
KRD100－500 |
KRD100－1000 |
KRD100－2000 |
KRD100－3000 |
|
Max Load (kg) |
100 |
200 |
300 |
500 |
1000 |
2000 |
3000 |
Working Table Size (mm) |
1100×1100 |
1300×1300 |
1800×1800 |
2000×2000 |
2200×2200 |
||
|
Shock Panel Size (mm) |
1600×2000 |
2100×2000 |
2000×2200 |
2400×2400 |
2600×2600 |
||
Shock Velocity Range (m/s) |
1.2～3.87 |
0.59～2.35 |
|||||
Incline Angle |
10°±1° |
||||||
Shock Velocity Error |
≤±5% |
||||||
Power Supply |
3-phase AC380V±10% 50Hz |
||||||
Working Environment |
Temperature range 0 ~ 40℃, Humidity≤80% (non-condensing) |
||||||
Installation Condition |
Special foundation or embedded chemical anchor bolts or expansion bolts on the leveled concrete floor |
||||||
Standards |
ISTA 1/2/3/6 Series, ISO 2244:2000, ASTM D880 |
||||||
Note: The parameters in the table are for reference only, and the parameters agreed upon by the supplier and the buyer shall prevail.
Standards
ISTA 1/2/3/6 Series: Shock-Incline Impact
ISO 2244:2000: 5.3.1 Inclined Plane Tester
ASTM D880: Standard Test Method for Impact Testing for Shipping Containers and Systems
