QSFP-40G-SR-BD Cisco 40 Gigabit Optical Modules BiDi Short-reach Transceiver

Description

Cisco 40GBASE-SR Bi-Directional QSFP Module for Duplex MMF

Dimensions

13.5 x 18.4 x 72.4 mm

   QSFP Port cabling specifications

Wavelength (nm)

832 - 918

Cable Type

MMF

Core Size (microns)

50.0

50.0

50.0

Modal Bandwidth (MHz-km)

500 (OM2)

2000 (OM3)

4700 (OM4)

Cable Distance

30m

100m

150m

Power Consumption (W)

3.5

Pull Tab Color

Gray

 Optical characteristics

Type

40GBASE-SR-BiDi, Duplex MMF

Transmit Power (dBm)

Max:+5 per lane

Min:-4 per lane

Receive Power (dBm)

Max:+5.0 per lane

Min:-6.0 per lane

Transmit and Receive Wavelength (nm)

832 to 918

Environmental conditions

Commercial temperature

+10 to 70°C (50 to 158°F)

Storage temperature

-40 to 85°C (-40 to 185°F)

Regulatory and standards compliance

Standards

•GR-20-CORE: Generic Requirements for Optical Fiber and Optical Fiber Cable

•GR-326-CORE: Generic Requirements for Single-Mode Optical Connectors and Jumper Assemblies

•GR-1435-CORE: Generic Requirements for Multifiber Optical Connectors

•IEEE 802.3ba (-SR4, -LR4)

•IEEE 802.3ae (-CSR4)

•QSFP+ MSA SFF-8436

•SFP+ MSA SFF-8431 and -8461

•RoHS 6

Safety

•Cable jacket of QSFP copper modules is UL E116441 Compliant

•QSFP copper cables are ELV Compliant
