Cisco GLC-SX-MMD 1000BASE-SX SFP Transceiver Module, MMF, 850nm, DOM

Name: Cisco GLC-SX-MMD 1000BASE-SX SFP Transceiver Module, MMF, 850nm, DOM
Brand: Cisco
SKU: 166988545
Availability: InStock

Cisco GLC-SX-MMD 1000BASE-SX SFP Transceiver Module, MMF, 850nm, DOM thumbnail-1

Cisco GLC-SX-MMD 1000BASE-SX SFP Transceiver Module, MMF, 850nm, DOM thumbnail-2

Cisco GLC-SX-MMD 1000BASE-SX SFP Transceiver Module, MMF, 850nm, DOM thumbnail-3

Cisco GLC-SX-MMD 1000BASE-SX SFP Transceiver Module, MMF, 850nm, DOM thumbnail-4

Cisco GLC-SX-MMD 1000BASE-SX SFP Transceiver Module, MMF, 850nm, DOM thumbnail-5

Cisco GLC-SX-MMD 1000BASE-SX SFP Transceiver Module, MMF, 850nm, DOM photo-1

Cisco GLC-SX-MMD 1000BASE-SX SFP Transceiver Module, MMF, 850nm, DOM photo-2

Cisco GLC-SX-MMD 1000BASE-SX SFP Transceiver Module, MMF, 850nm, DOM photo-3

Cisco GLC-SX-MMD 1000BASE-SX SFP Transceiver Module, MMF, 850nm, DOM photo-4

Cisco GLC-SX-MMD 1000BASE-SX SFP Transceiver Module, MMF, 850nm, DOM photo-5

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

Cisco

Place of Origin:

China

Model Number:

GLC-SX-MMD

Contact Supplier Request Quote Chat Now

Bwy Technology Co., Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

GUANGZHOU

Delivery Detail:

1 days

Product Details
Company Profile
Contact Us

Brand Name Cisco

Place of Origin China

Model Number GLC-SX-MMD

GLC-SX-MMD Overview

The GLC-SX-MMD 1000BASE-SX SFP is made for Multimode Fiber only.

The 1000BASE-SX SFP, compatible with the IEEE 802.3z 1000BASE-SX standard, operates on legacy 50 μm multimode fiber links up to 550 m and on 62.5 μm Fiber Distributed Data Interface (FDDI)-grade multimode fibers up to 220 m. It can support up to 1km over laser-optimized 50 μm multimode fiber cable. 850-nm wavelength, extended operating temperature range and DOM support, dual LC/PC connector.

GLC-SX-MMD Specification

SFP Port Cabling Specifications
Product	Wavelength (nm)	Fiber Type	Core Size (μm)	Modal Bandwidth (MHz* Km)***	Operating Distance (m)
1000BASE-SX	850	MMF	62.5	160 (FDDI-grade)	220 (722 ft)
			62.5	200 (OM1)	275 (902 ft)
			50	400 (400/400)	500 (1,640 ft)
			50	500 (OM2)	550 (1,804 ft)
			50	2000 (OM3)	1000 (3281 ft)
1000BASE-LX/LH	1310	MMF*	62.5	500	550 (1,804 ft)
			50	400	550 (1,804 ft)
			50	500	550 (1,804 ft)
		SMF	-**	-	10,000 (32,821 ft)
1000BASE-EX	1310	SMF	-**	-	40,000 (131,234 ft)
1000BASE-ZX (GLC-ZX-SMD)	1550	SMF	-	-	Approximately 70 km depending on link loss
1000BASE-BX-U	1310	SMF	-**	-	10,000 (32,821 ft)
1000BASE-BX-D	1490	SMF	-**	-	10,000 (32,821 ft)
