AR2220E Overview
Huawei AR G3 AR2200 series router AR2220E is the next-generation enterprise-class routers based on the Huawei proprietary Versatile Routing Platform (VRP) and designs for midsize enterprise or branch office. It includes 3 Gigabit Ethernet WAN (RJ-45 or SFP) port, 2 USB, 4 SIC, 2 WSIC, 1 DSP Slot.
AR2220E Specification
| AR2220E Specification | |
DSP slots |
2 |
USB 2.0 ports |
2 |
Mini-USB ports |
1 |
Console port |
1 |
Memory |
1 GB |
|
Flash(default/ max**) |
512MB/ 4 GB |
Maximum power |
150W |
Redundant Power Supply External RPS |
none |
AC power |
100 V-240 V |
Frequency |
50 Hz/60 Hz |
DC power |
-48 V~-60 V |
Dimensions(height x width x depth) |
44.5 mm x 442 mm x 420 mm |
Weight |
4.95 kg(without power module and interface card) |
Ambient temperature |
0oC - 45oC |
WAN speed with services*** |
800 Mbps |
Firewall performance (large packets) |
3Gbps |
Number of recommended users |
300 |
Fixed WAN ports |
3xGE (1xcombo port) |
SIC slots |
4 |
WSIC slots(default/max**) |
2/4 |
XSIC slots(default/max**) |
0/2 |
EXSIC slot |
0 |
