ZONHOW Universal Pull Out Test Equipment, Universal Pull Testing Machine,
Materials Pull Out Tester
Summary
Tensile test machines are universal testing machines specially configured to evaluate tensile strength of specimens. Our tensile testers will measure characteristics such as ultimate tensile strength, yield strength, elongation and modulus. Each tensile test machine is configured to your testing needs by our application engineers with the correct controller, grips, and accessories. Due to our modular machine design, your tensile tester can also be equipped to perform other applications such as compression, cyclic, shear, flexure, bend, peel, and tear just by adding fixtures.
Application Industries
Universal tensile strength testing machine is widely used in most of industries: Rubber & Plastics; Metallurgical iron and steels; Manufacturing machinery; Electronic equipments; Automobile production; Textile fibers; Wire and cables; Packaging materials and footstuffs; Instrumentation; Medical equipments; Civilian nuclear energy; Civil aviation; Colleges and universities; Research laboratory; Inspection arbitration, technical supervision departments; Building materials and so on.
Specifications of DZ-101 Series Universal testing machine
Series |
DZ-101 Computer Servo Tensile Testing Machine |
Capacity |
100. 200. 500. 1000. 2000kg |
Unit Switchover |
G, KG, N, LB |
Display Device |
PC |
Resolution |
1/250,000 |
Accuracy |
±0.5% |
Effective Max. Stroke |
800mm (Column height 1420mm) |
Test Speed |
0.1-500mm/min (adjustable ) |
Motor |
Panasonic Servo Motor |
Screw |
High Precise Ball Screw |
Elongation Accuracy |
0.001mm |
Power |
AC220V, 50HZ or customized |
Accessories parts |
One set of tensile clamp, One set of computer, English software CD |
