90/180 peeling strength test machine tester
Introduction——90/180 peeling strength test machine tester
- 90/180 peeling strength test machine tester is designed and manufacture in accordance with the relevant GB17200 specification, performance indicators in line with the GB/T2790 (adhesive 180 ° peel strength test),GB/T2791 T peel strength test (adhesive), GB2792 (pressure sensitive adhesive tapes 180 ° peel strength measurement), GB4850 signals.a strength test (low speed), GB7754 (shear strength test), GB8808 (composite film peel strength test), ZBY28004 (heat sealing strength measurement), GB13022 tensile test (film), GB7753 (pressure sensitive adhesive tape pull test) test methods such as request.
- 90/180 peeling strength test machine tester can do all kinds of paper, film, rubber, plastic, fabric, waterproof material, non-woven fabrics, metal wire, metal foil,. Metal mechanics, and the longitudinal and transverse tensile, tensile and tear properties and mechanical properties test, composite film, pressure sensitive adhesive materials such as stripping, splitting, shear strength test, elongation at break test, heat sealing tensile, tear, strength test, etc.
Features——90/180 peeling strength test machine tester
1.Provide the capacity of two groups of test space, let the operator has a bigger scope, especially the raw material and finished product testing strength gap is bigger, the most suitable. On the type of be born type, mainly in the steel wire, small screw type of fabric and other industries the most commonly used. The biggest test of 50 kn force, long stroke and has two test space, can be installed capacity of two different sensors, used in testing strength difference is very big occasions, such as in the spring industry, steel wire, rubber and plastic materials such as the analysis of the test.
2.It can be pulled off automatically and the peak is maintained;Measuring strength of tension, pressure and input parameters;The tensile force value is determined, and the force value is elongated.Display curve (force value, displacement);Single point speed regulation (1 -- 500mm/min), single point speed regulation (1, 2, 5, 10, 20, 50, 100, 200, 500), stepless speed regulation can be set to any accuracy within 1 -- 500 range.The accuracy of each measurement is plus or minus 1%.The machine adopts closed-loop control method with high control precision.
Technical parameters——90/180 peeling strength test machine tester
| Range of speed | 50~500mm/min |
| Effective force ranage | 0.4%~100% |
| Motor | Panasonic sevor motor |
| Resolution | 1/250,000 |
| Capacity choice | 2,5,10,20,50,100,200Kg |
| Effective tensile space | 650mm/800mm/1000mm(your choice) |
| Accuracy | ±0.5% |
| Force relative error | ±0.5% |
| Displacement relative error | ±0.5% |
| Test speed relative error | ±0.5% |
| Accessories | computer, printer, system operation manual |
| Operation method | windows operation |
| Power | 220V ±10% 0.2KW/0.4KW |
| Stroke protection | Upper and lower protection, prevent over preset |
| Force protection | system setting |
| Emergency stop device | Handling emergencies |
Details show——90/180 peeling strength test machine tester
Conform to the standards——90/180 peeling strength test machine tester
The testing machine of tape stripping force is designed and manufactured in accordance with GB17200 specifications. The performance indexes meet the following test standards:
- GB/T2790 (adhesive 180 ° peel strength test),
- GB/T2791 (adhesive T peel strength test),
- GB2792 (pressure sensitive adhesive tapes 180 ° peel strength measurement),
- GB4850 (low-speed uncoil strength test),
- GB7754 (shear strength test),
- GB8808 (composite film peel strength test),
- ZBY28004 (determination of heat sealing strength),
- GB13022 (film tensile test),
- GB7753 (pressure sensitive adhesive tape tensile test)
Additional application——90/180 peeling strength test machine tester
1.Tested sample: plastic films, laminated materials, adhesive tapes, adhesive bandage (plaster), release paper, plastic films, leather, rubber & plastic, paper, fiber, etc.
2.Different test with different grips: tensile, peel, tear, heat seal, adhesive, bend and open force.
3.Deformation under defined load: Test deformation under defined load of tested sample
4.Load under defined deformation: Test load under defined deformation of tested sample
5.Software can issue word/excel report with results for max. force, elongation, tensile strength, peel strength, tear strength, compression strength, etc.
Universal tensiel tester(5T) Universal tensile tester(200kg) Mobile drop tester(1.5/2m) Wire elongation tester
Humidity climatic chamber Dust test chamber 339 Abarasion tester Moving die Rheometer
We have professional packing workers to pack your products!
Packing:
1. Out packing:Standard export wooden case.
2. Inner packing:With careful stretch film wrap product, hard wood board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your goods.
Shipping:
You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the shipping cost after receipt ofyour order. It's more preferable for you to provide us with your own FEDEX/DHL account number so that the delivery charge can be charged directly from your account.
Though 11 years of continous development, our company has established the main products line of universal strength testing machines for tension ,compression, flexure, and shear, environment testing chambers and abrasion testing machines. Our equipment is used in over 80 countries wordwide and supported by a network of offices and approved agencies. Our products are used in all industries and educational sectors and we have an enviable reputation for innovation, quality product and excellent customer support.
Our Products
1.Are your company a trading one or a factory ?Factory + trade (integration),10 years focusing on test instruments field,3 years exporting experience.
OEM is also acceptable for us.
2.How to choose the most suitable products?
Our professional team will give you the best suggestion as long as you tell us what kind of test you
need to do and the required specification.
3.What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20
working days after deposit receipt. If you are in urgent need, we can consider making special
arrangement for you.
4.Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines according to
your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
5.Can we visit your factory before order?
Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to
arrange hotel and pick up you from airport.
6.Do you have customers of our country before?
Now our testing machines have been sold to more than 26 countries, like USA, Canada, Russia,UK,
Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Thailand and Vietnam,Iran,
Brazil and so on.
7.How about your warranty?
Generally, our warranty is one year. Within the warranty period, we can offer technique support and
part parts change, necessarily, our engineers may go to your place for better service.
8.How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many
testing machines abroad by sea or by air without damage.
9.What is the order process?
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and
debugging - balance payment - packing - delivery - customer receiving - after service.
10.How to install and use the product
The product is shipped with an operating instructions and video of English version.
