Equipment summary——Universal Tensile Fatigue testing machine
Universal Tensile Fatigue testing machine adopts the mechanical and electrical integration design, mainly composed of the measuring force sensor, transmitter, microprocessor, load driving mechanism, computer and color inkjet printer. The plastic tension tester applied force on the sample.Special tests for stretching, bending, compression or shear are classified according to the direction of the strain in the sample and the speed of the force.The basic test is performed by a standard plastic tensile testing machine.They are usually loaded at a speed range of 0.1mm/min to 500mm/min, and different materials require different test speeds.
What items we can test ?(Plastic computer control tensile testing machine)
- Tensile stress
- The tensile strength
- Breaking strength
- Breaking elongation
- Set the stretching stress
- Constant stress elongation
- Stress value
- Tear strength
- Arbitrary value of force
- Arbitrary extension rate
- Pull force
- Adhesion and peak value
- Pressure test
- Shear force stripping force experiment
- Bending tests
- Experiment of pulling force puncture force
Standard of test samples and fixtures——Universal Tensile Fatigue testing machine
extensometer(According your products, recommend you suitableone)
Standard fixtures
For example
Applications——Universal Tensile Fatigue testing machine
Scope of its service industry in scientific research institutes, the arbitration inspection institutions, colleges and universities, and rubber, tires, plastics, wire and cable, footwear, leather, textiles, packaging, building materials, petrochemical, aviation and other industries, for material development, physical properties testing, teaching research, quality control, incoming inspection, production line indispensable testing equipment such as random inspection.
Test Standards——Universal Tensile Fatigue testing machine
GB/T16491,GB/T1040,GB/T8808,GB/T13022,GB/T2790,GB/T2791,GB/T2792,GB/T16825,GB/T17200,GB/T3923.1,GB/T528,GB/T2611,GB/T6344,GB/T20310,GB/T3690,GB/T4944,GB/T3686,GB/T529,GB/T6344,GB/T10654,HG/T2580,JC/T777,QB/T2171,HG/T2538,CNS11888,JISK6854,PSTC-7,ISO37,AS1180.2,BSEN1979,
BSENISO1421,BSENISO1798,BSENISO9163,DINENISO1798,GOST18299,DIN53357,ISO2285,ISO34-1,ISO34-2,BS903,BS5131,DINEN12803,DINEN12995,DIN53507-A,DIN53339,ASTMD3574,ASTMD6644,ASTMD5035,
ASTMD2061,ASTMD1445,ASTMD2290,ASTMD412,ASTMD3759/D3759M
Technical parameters——Universal Tensile Fatigue testing machine
