WEW-D Computer display Hydraulic universal and Compression testing machine price
skype:kason004 whatsapp:+86 18253185736
1. Application
The machine adopts hydraulic loading, Computer Display, easy and convenient to operate.
It is mainly used to execute the tension, compression, bending, flexural etc. test for metal
materials. Attached with simple accessories and devices, it can be used to test wood, concrete,
cement, rubber, and so on.It is very suitable for making test to different metal or nonmetal
materials under high toughness and hardness against extreme big loading force.
2. Standards
ISO6892, BS4449,ASTM C39,ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards.
3..Main Technical Specifications
Model |
WEW-300D |
WEW-600D |
WEW-1000D |
WEW-2000D |
Max.load |
300kN |
600kN |
1000kN |
2000kN |
Structure |
6 column |
|||
Control way |
loading process manual control,computer automatic data dealing |
|||
Load accuracy |
≤±1% /≤± 0.5% |
|||
Load range |
2%-100%FS /0.4%-100%FS |
|||
Load resolution |
1/300000 |
|||
Deformation Measurement Range |
2%~100%FS |
|||
Deformation accuracy |
≤±1%/± 0.5% |
|||
Displacement resolution |
0.01mm |
|||
Displacement error |
≤±0.5% |
|||
Max.piston stroke |
250mm |
|||
Max piston moving speed |
0-140mm/min |
0-90mm/min |
0-50mm/min |
0-70mm/min |
Crosshead lifting speed |
200mm/min |
|||
Max. tension test space |
650mm (can customize) |
900mm |
||
Max.Compression Test Space |
500mm (can customize) |
800mm |
||
Column clearance |
430mm |
475mm |
525mm |
760mm |
Clamping method |
Hydraulic clamp |
|||
Round specimen clamping range |
Φ13-Φ40mm (Φ6-Φ13mm , Φ40-Φ50mm Optional ) |
|||
Flat specimen clamping range |
0-15mm (15-30mm Optional) |
|||
Flat specimen clamping width |
80mm |
|||
Compression plate size |
φ160mm |
|||
Bending roller distance |
450mm |
|||
Width of bending rollers |
120mm |
|||
Power supply |
3-phase,AC220V, 60Hz |
|||
The picture of the hydraulic uiversal testing machine
we major in testing machine more than 10 years,has exported to USA ,Germany,
WEW-D 300 600 1000 2000kN Computer Display Tension Comperssion Test Equipment, Tensile Machine, Hydraulic Universal Test Machine
The foreign customers visit our factory
