WAW-1500H 1500KN 150 Ton Computerized Electro-hydraulic Servo Universal Tensile Testing Machine

FOB Price

US$ 7,000 - 10,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	KASON		Place of Origin	Shandong, China
Model Number	WAW-1500H		Power	Hydraulic

WAW-1500H 1500KN 150 Ton

Computerized Electro-hydraulic Servo Universal Tensile Testing Machine

1.Application:

The machine adopts hydraulic loading, Computer Control, easy and convenient to operate.

It is mainly used to execute the tension, compression, bending, shearing, flexural etc. test for metal materials.

Attached with simple accessories and devices,it can be used to test wood,concrete,cement,rubber,and so on.

It is very suitable for making test to different metal or nonmetal materials under high toughness and hardness

against extreme big loading force.

2.Standards:

ISO6892, BS4449, ASTM C39, ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN Standards.

3.Main Specifications:

Model	WAW-1500H
Structure	6 Column (Four Columns Two Ball Screws)
Control Way	Constant Stress Uniform Deformation Constant Displacement, Three Closed Loop Control And Program Control
Max. Load	1500 KN (150 TONS)
Load Accuracy	≤± 1%
Load Range	2%~100%FS (30KN~1500KN)
Load Resolution	1/300000
Deformation Measurement Range	2%~100%FS
Deformation Accuracy	≤± 1%
Displacement Resolution	0.01mm
Displacement Error	≤±0.5%
Max. Piston Stroke	250mm
Crossbeam Lifting Speed	200mm/min
Max. Tension Test Space	850mm (Can Be Customized)
Max. Compression Test Space	650mm (Can Be Customized)
Clamping Method	Hydraulic Automatic Clamping
Round Specimen Clamping Range	Φ13-Φ26mm, Φ26-Φ40mm, Φ40-Φ60mm
Flat Specimen Clamping Range	0-20mm (Optional: 20-40mm)
Flat Specimen Clamping Width	125mm
Flat Specimen Clamping Length	100mm
Compression Plate Size	Φ 160mm
Bending Roller Distance	450mm
Width Of Bending Rollers	120mm
Power Supply	3-phase,AC380V, 50Hz (Can Be Customized)

4.The Packing Way Of Our Export Machines:

5.The Realistic Pictures Of Our Factory:

6.Our Process Of Foreign Trade:

7.Our company can also produce the customized testing machines as clients' requirements.

You can contact me as the below information.
