HTD Dial Tension Force Gauge
Application:
Our range of Dial tension force meter(gram gauges) provide a simple, quick and easy way of measuring forces from 2 to 500 gram-force. It measures in both directions clockwise and counter clockwise. Available in four sizes: HTD,HTD,HTD-Z,HTD-Z. Available with flat or round tips and with N or g unit.
From electronic relays and switches to compression and extension springs through to orthopedics and orthodontics, our tension meter(gram gauge) is used in a myriad of applications to measure very low force.
Specifications:
Model |
HTD-10 |
HTD-30 |
HTD-50 |
HTD-100 |
HTD-150 |
HTD-300 |
HTD-500 |
Capacity |
10g |
30g |
50g |
100g |
150g |
300g |
500g |
Resolution |
0.2g |
0.5g |
1g |
2g |
2.5g |
5g |
10g |
Calibration mode |
2-10-2g |
6-30-6g |
10-50-10g |
20-100-20g |
30-150-30g |
60-300-60g |
100-500-100g |
Net weight |
65 g |
||||||
Gross weight |
140 g |
||||||
Accuracy |
+/-2% of full scale |
||||||
Model |
HTD-0.1 |
HTD-0.3 |
HTD-0.5 |
HTD-1 |
HTD-1.5 |
HTD-3 |
HTD-5 |
Capacity |
0.1N |
0.3N |
0.5N |
1N |
1.5N |
3N |
5N |
Resolution |
0.005N |
0.01N |
0.02N |
0.05N |
0.05N |
0.1N |
0.2N |
|
Calibration mode |
0.02-0.1-0.02N |
0.06-0.5-0.06N |
0.01-0.5-0.01N |
0.2-0.1-0.2N |
0.3-1.5-0.3N |
0.6-3-0.6N |
1-5-1N |
Net weight |
65 g |
||||||
Gross weight |
140 g |
||||||
Accuracy |
+/-2% of full scale |
||||||
