Aluminum frame tempered glass window

Aluminum frame tempered glass window

U-Value	0.8-2.0
Sound insulation	30-48dB
Water Penetation	4500Pa
Wind Resistance	450 Pa
Name	Aluminum frame tempered glass window
Material	Aluminum profile, glass, hardware, rubber strip
Opening styles	toplights, sidelights, sliding, casement, folding, awning, tilt-turn
Standard Certificate	Comply with AS2047 AUS standard
Aluminum profiles	6063-T5 aluminum alloy with different color surface
General Glass	Double glazed glass 5+9+5/ 6+12+6 Laminated glass 3+0.38+3/ 5+0.76+5 Tempered glass 6mm, 10mm, 12mm
Hardware	German brand Roto/ Chinese top brand Kin Long
Application	Housing series, residentials series, commerdial series

Rocky are able to offer a broad range of windows to suit the vast majority of housing and building. We also developed a complete range of solutions, to satisty even the most demanding requirements.

ROCKY 110 Passive House Windows: Uw0.8w/m2.k

Rocky Aluminum profile

Rocky Glass

Tempered Glass
Tempered glass is made by heating ordinary glass to its softening point and then suddenly cooling down to form compression in the surface layer of the glass, which processing make full tempered glass above 4 times stronger than annealed glass of equal thickness.
Characteristics
Safety: once breakage occurs, the glass disintegrates into tiny harmless pieces
High strength: above 4 times stronger than annealed glass of equal thickness
Strong wind resistance: 1.5-3 times stronger than annealed glass of equal thickness
Excellence thermal stability, which can withstand 300ºC abrupt change of temperature
Types
Tempered glass, Heat strengthened glass, Tempered glass with hest soak, Bent tempered glass
Thickness
3- 19mm, etc.
Colors
Clear, Ultra Clear, French Green, Dark Green, Euro Grey, Dark Grey, Ford Blue, Dark Blue, Ocean Blue, Euro Bronze, Dark Bronze, Golden, Pink, Yellow, etc.
Or mirror, patterned glass, decorative glass are available tempered.
Laminated Glass
Laminated glass is processed with special technology under high temperature and high pressure by adding one or more layers of Polyvinyl Butyral (PVB) or Ethylene vinyl acetate (EVA) with tough and strong binding between or among two or more glass sheets.
Characteristics
Excellent safety: the glass are bound by PVB can stop external force attack, even glass broke, the chips will not fall down, avoiding harm to person
Energy efficiency: stop the transmission of solar heat and reduce cooling loads
Hurrican, cyclone and bullets resistance
Excellence UV shielding performance(up to 99%)
Excellence sound control and noise reduction performance
Types
Laminated glass with clear or colored PVB film
Laminated glass with clear, colored or paint EVA film, fabric
Laminated glass with DuPont SGP film
Thickness
3- 19mm(single glass)
0.38- 2.28mm(film)
Colors
Clear, Ultra Clear, French Green, Dark Green, Euro Grey, Dark Grey, Ford Blue, Dark Blue, Ocean Blue, Euro Bronze, Dark Bronze, Golden, Pink, Yellow, Milk White, Red, etc.

Rocky hardware

Rocky have cooperation relationship with ROTO system, and famous brand like KIN LONG, HOPO

Rocky Development

Rocky Development Co.,Ltd (Qingdao Rocky Window Co.,Ltd) is fast growing manufacturer& supplier of Window, Doors as well as Aluminum Profiles. We offer a wide range of products to residential, commercial, industrial applications. Operating from a state of art fabrication facility base in Qingdao, China. Our technologically advanced products are readily available to demanding clients for new construction, replacement, remodeling and upgrading.

At Rocky,our primary goal is to ensure a pleasant experience for our valued customers. Rocky customers not only benefit from our quality products and competitive prices, but also personalized service,flexibility,short lead time and reliability as well. Aluminum frame tempered glass window is committed to the highest standards, assembling your contemporary demands for living quality, environmental harmony, and energy efficiency.

Step1. corners are wraped by cardboard from collision damage;

Step2. Frames are warpped by protective tape from scratches;

Step3. Fix window & doors on iron pallets by alu. strips;

Step4. Reinforce windows & doors with plastic belts;

Step5. PE films cover to keep sea water away;

Step6. Tie up iron pallets in container with plastic belts;

Step7. Fill in the space between each two iron pallets with air bags to keep stable.

Step8. Aluminum window shipped within 15 days after the payment.

Before Sale Service

1. Pro fessional consulting

2. Offer optimized proposal on competitive price.

3. Warmly welcome to factory visit and send samples for detection.

Prodection Period Service

2. Update progress schedule regularly and keep customers posted.
