RH-500 Automatic Fabric Spreader
Technical Features
1,PLC control LCD touch system: choosing or setting functions only by touching the function keys on the touch screen
2,The machine can set up the amount of layers (maximum 100 layers). When the layers reaches the preset number or no cloth will automatically shut down
3, Keep feeding and spreading fabrics without tension, no cloth stretching phenomenon appeared
4,Functions of machine can be set up simply. Single person can operate, save manpower, without manual intervention
5,Equipped with the emergency stop device. The fabric that is spreading not appears dragging case when stop
6,The path of cloth cutting knife can be adjustable depend on width of fabrics. It can save extra time in the progress of moving back and forth
7,Automatic edge-align device assure the selvage neatly, saving fabrics
8, Humane emergency stop devices to prevent sudden security maintenance
9, Suitable for knitted fabrics, woven fabrics, pre-shrinking fabric cloth, one-way spreading
Technical Parameters
|
Fabric width |
1500mm-3500mm |
|
Table width |
1880mm-3900mm |
|
Spreader speed |
0-60 m/min |
|
Weight |
1250 KG |
|
Power |
380V(50Hz/60Hz) 3KW |
|
Dimension |
3800mm*2400mm*1360mm |
