Waste Carton Paper ,plastic Pet Bottle Baler Machine / Hydraulic Full Automatic Baler Press
- Ningbo
- T/T Credit Card
You May Like
-
Automatic Shrink Sleeve Labeling Machine for Cup
-
Low Speed PVC PET Shrink Sleeve Center Seaming Machine For Bottle
-
PVC PET Shrink Sleeves Sheet Cutting Machine for Bottle ,battery Packaging
-
PVC PET Bottle Label Gluing Machine
-
High Speed PVC PET Shrink Sleeve Center Gluing Seaming Machine For Small or Big Water Bottle Head Cover Also
-
Stainless Steel Manual Mineral Water Bottle Label Sleeve Shrink Machine
Product Details
| Brand Name | XIAOHIA | Place of Origin | Zhejiang, China | |
| After-sales Service Provided | Engineers available to service machinery overseas | Condition | New |
box
Product Description
Feature of waste plastic press pet bottle baler machine
waste paper ,plastic pet Bottle Baler Machine / hydraulic full automatic baler
(1)This series machine mainly is used for baling cartons, cotton yarn, plastic, wood, etc. It is designed as vertical structure, hydraulic transmission, electrical control and manual binding.
(2)Usually the pressureforce of this series is from 10 ton KN to 60 ton KN, the efficiency is 4 ~ 6 pieces per hour. The weight of each piece is from 30 Kg to 300 Kg according to the material.
(3)Also, we can produce the machine according to the requirement from customer.
a.Adopting a hydraulic drive mechanism, Use less energy, with huge operating energy
b.Electric button control, it can reaches manual adjusting and semi automatic control
c. Independent feeding opening with automatic pulling out installation, to reduce labor force.
d.It can be made according to the demands of customers
Waste plastic press PET bottle baler machine hydraulic plastic bottle baling machine - HW
|
Model |
Force |
Bale size |
Bale weight |
Efficiency |
Power (KW) |
Machine weight |
Size (mm) |
|
DB10-6040 |
10 Ton |
600*400 mm |
30-50 KG |
4-6 bale/hour |
2.2 |
1000 KG |
900*650*2100 |
|
DB20-8060 |
20 Ton |
800*600 mm |
80-100 KG |
4-6 bale/hour |
4 |
1100 KG |
1000*750*2750 |
|
DB30-8060 |
30 Ton |
800*600 mm |
100-130 KG |
4-6 bale/hour |
5.5 |
1300 KG |
1000*750*2750 |
|
DB30-11070 |
30 Ton |
1100*700 mm |
130-150KG |
4-6 bale/hour |
5.5 |
1700 KG |
1350*850*3200 |
|
DB40-11070 |
40 Ton |
1100*700 mm |
180-200KG |
4-6 bale/hour |
7.5 |
1800 KG |
1350*850*3200 |
|
DB40-12080 |
40 Ton |
1200*780 mm |
200-240KG |
4-6 bale/hour |
7.5 |
2050 KG |
1600*1050*3300 |
|
DB50-12080 |
50 Ton |
1200*800 mm |
320-350KG |
4-6 bale/hour |
7.5 or 11 |
2600 KG |
1600*1050*3300 |
|
DB60-12080 |
60 Ton |
1200*800 mm |
380-420KG |
4-6 bale/hour |
11 or 15 |
2900 KG |
1600*1050*3300 |
|
DB80-12080 |
80TON |
1200*800 mm |
450-480KG |
4-6 bale/hour |
15 |
3300 KG |
1600*1050*3300 |
|
DB100-12080 |
100TON |
1200*800 mm |
500-550KG |
4-6 bale/hour |
15 |
3700KG |
1600*1050*3300 |
|
DB120-150100 |
120TON |
1500*1000 mm |
650-700KG |
4-6 bale/hour |
15 or 18.5 |
4300KG |
2100*1550*3300 |
|
DB150-150100 |
150TON |
1500*1000 mm |
850-900KG |
4-6 bale/hour |
18.5 |
5100KG |
2100*1550*3300 |
-rebound device.
