Stroboscope for Inspection Machine

box

Stroboscope for inpection machine

The instrument is widely used in the packaging and printing industry: it can detect the high-speed printing process color registration; ink color, die cutting, punching, folding, etc.; the whole online monitoring of the material, labels, forms, flexo, intaglio printing Marking line symbol detection; UV component control for fluorescent printing quality inspection, final quality inspection of paper cutter and reel, dynamic analysis of folding machine, synchronous control of engine and gear, etc. Used in the textile industry: Testing the rotational speed of textile spindles and yarns on spinning machines and winding machines; Detection of weft yarns on mechanical knitting machines: Check whether there are skewed wefts before the fabric leaves the frame; Monitor the running status of spinning lines and other parts on the sewing machine : It can detect the spindle speed and the loom weft yarn. For machinery manufacturing: Non-contact rotational speed measurement, detection of oscillation amplitude and vibration frequency; use of “slow release” function display for complex motion processes, detection of the status of tools such as drill bits and boring tools in production: Measurement of slip coefficients of clutches and conveyor belts: Detection of gear tooth gaps in the gearbox: Various types of rotor, gear teeth, and vibration equipment can be diagnosed. Can also be used for aircraft manufacturing, automotive manufacturing, cable manufacturing, mining and packaging, shipbuilding, steel, chemical, optical [high-speed photography, image processing], medical and other industries.

DT316N rechargeable stroboscope
First, the main features:
Adopt imported shuttle encoder knob to adjust frequency accurately and quickly
External triggering of the pattern, can achieve automatic tracking of the pattern
Double frequency, double current operating frequency, for coarse adjustment
Half-frequency, halving the current operating frequency, for coarse adjustment
Second, technical parameters:
Total power: the maximum power is less than 45W
Power supply: DC12V (battery pack) / 2A/50HZ
Frequency range: Internal trigger 1 rev/Min~18000 rpm/Min
                 Trigger 1 turn/Min~30000 turn/Min
Ambient light: less than 10,000 lux
Charging time: <6H
Lamp: Original German Hyman, Lifetime 10,000,000 times
External trigger signal range: 5V~12V pulse signal
Dimensions (mm): 235X120 (82) X120 (82)
