High speed pvc shrink sleeve making machine WITH EPC

APPLICATION

HZ300 High speed PVC shrink sleeve making machine

is specialized in sealing PVC,PET etc. sheet film to be sleeved roll label.(like beverage bottle label)

PARAMETER

Raw material

PVC,PET,PET-G SHRINKABLE FILM

Film thickness

20-80 um

Max. unwinding diameter

Φ450mm

Max. unwinding width

60-600mm

Center sealing precision

±0.3mm

Max. rewinding diameter

Φ700mm

Max. rewinding width

280mm

Max. sealing speed

300m/min

Rewinding tension range

5N-50N

Total machine power

3.5kw

Voltage

380V 50hz China.(Depend on customer)

Measurement

3700mm*1500mm*1750mm(L*W*H)

 Weight

 1Ton

FEATURE

Unwinding system

1. 3inch airshaft

2.Edge Position Controlling System

3.Automatic Unwinding tension controlling system

Pump gluing system

ntrolled by PLC

2.Gluing quantity controlled by pump

3.Machine stop ,gluing getting back ,no pollution on film

Rewinding system

1.3inch airshaft

2. Automatic Rewinding tension controlling system

Flash light for inspection keeping the same speed with machine

Model No.

ZF-250

ZF-300

Max.Width of Material

250mm

300mm

Max. Speed

80m/min

80m/min

Total Power

2.2Kw

2.5Kw

Weight of Machine

500kg

700kg

Machine Dimension(mm)

2820x1050x1100

2820x1200x1100

Usage:

1.This machine is to cut all kinds of packing material to be sheet before they used to pack the goods,such as drinking package,candy packing film,wine bottle packing,tape,paper etc.

2.This machine is equipped with computer to set the bag length and batch etc.to make the bag automaticlly,also the machine is with photocell, automatic material feeding device,automatic constant temperature control device, electrostatic removing device,automatic counting and alarm device etc.

Remark:

We also have wider width machine,if you want to make special length and width,please feel free to contact us.we will provide you details.thanks....
