ASTMD 2843 Auto Control Intelligence Running Light Flux Smoke Density Detector Tester Meter

ASTMD 2843 Auto Control Intelligence Running Light Flux Smoke Density Detector Tester Meter photo-1
ASTMD 2843 Auto Control Intelligence Running Light Flux Smoke Density Detector Tester Meter photo-2
US$ 2,300 - 4,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
Sansing
Place of Origin:
Zhejiang, China
Model Number:
JCY-2
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Sansing
Place of Origin Zhejiang, China
Model Number JCY-2
Product Description

Application:

Smoke density tester meet specified in international standard specifications and requirements, can be used to measure and describe materials, products, components, response to heat and flame, in the controlled laboratory conditions. Measure static produce smoke of building materials under the experimental conditions of combustion or decomposed .


Feature:
1. The equipment is controlled by PLC, with strong logic, intelligent and stable operation.
2. Autonomous develop software can satisfy the various operations, records, curves and results of the test.
3. Automatic control mode can automatically control equipment operation, automatic detection and automatic collection, automatically display experimental curves and automatically generate experimental test results;The luminous flux can be automatically corrected

Technical Parameters
Measurement range of smoke density
(0-100) %
The calibration error of the standard lens
<3%
Working pressure of burner
276 KPa adjustable
Burning lamp
Bunsen burner
length of 260 mm
nozzle diameter of 0.13 mm, with smoke box into a 45 ° Angle;
Apply flame 4min to the sample;
Photoelectric system
light source is light bulb, power 15W, working voltage 12V;
Receiver
dedicated light sensor
Air source
propane gas, (customer's own)
Power
AC220V ±10% 50HZ 300W
Ventilation system
this machine has a powerful exhaust fan. After the test, the exhaust can be discharged out of the air.
Product Show
Our Company
Certifications
Packing & Delivery
FAQ

Q: Are you trading company or manufacturer ?
A: We are the manufactory ,in this area for 20years

Q: How long is your delivery time?
A:  If the products  in stock, generally 5-10 days,.if stockout 15-20 days  ,according to the  quantity of  order.

Q: Do you provide samples ? is it free ?
A: Yes, we could offer the sample for your test , but its not free.Hope to understand the high cost of products for high quality

Q: What is your terms of payment ?
A: Payment amount<=1000USD, 100% in advance. Payment amount >=1000USD, 30% T/T in advance ,balance as the B/L copy
