Application:
The UL94 Horizontal Vertical Flame Chamber is designed for the flammability testing of plastic materials used in consumer electric devices and appliances per UL94. The chamber is constructed of stainless steel with a black interior and large sliding window for easy viewing. The Test chamber includes a fully adjustable specimen support and a precision metered gas burner. Three digital timers with remote control are mounted on the inside back wall of the chamber, allowing for precise and simplified line-of-sight operation.
The horizontal vertical burning tester is mainly used to grading the flammability of V-0, V-1, V-2, HB, and 5V materials. It is also applicable to the research, production and quality inspection departments of electrical and electronic products and their components, such as lighting equipment, low-voltage electrical appliances, household appliances, machine tools, electrical machinery, power tools, electronic instruments, electrical instruments, electrical connectors and accessories. In the field of insulation materials, engineering plastics or other solid combustible materials.
Features:
* The horizontal vertical burning test machine is composed of a test part and a control part, and adopts an integrated design to facilitate on-site installation and debugging. The test chamber casing and important parts are made of stainless steel, which is resistant to smoke and gas.
* The control system is highly automated and has automatic ignition. During the test, the test object automatically follows the flame in both vertical and horizontal directions.
*The temperature and time numbers show that the observation and recording are convenient and the use is stable and reliable.
* Burner angle adjustable to 0º, 20º, 45º
* Flexible iris hand access ports
* Remote burner positioning
* Sliding tempered glass viewing window
* Removable burner carriage assembly
* Flexible laboratory fixturing
* Interior light
* Digital timers located in line of sight with specimen
* Digital timers with resolution of 0.1 s
* Remote control with push button reset for in-chamber event timing.
* Electrical gas shut-off solenoid
* Gas control system
* Flame confirmation kit (ASTM D5207)
Option
Voltage and Frequency Available:
120 V 60 Hz, 1.5 A
230 V 50 Hz, 0.75 A
Standard
Reference Test Standards: * UL 94
* ASTM D635, D3801, D4804, D5048, D4986,
* IEC 60695 Part 11-10
* IEC 60695 Part 11-20
* IEC 707 (partial), ISO 9772 and ISO 9773
If you are not sure about certain parameters of the UL94 The UL94 Horizontal Vertical Flame Chamber ,please let us know your inquiry and we are very happy to give you professional technical advice and support services. Our services are not limited to standardized Horizontal Vertical Flame Chamber, but also include specific consulting, design, R&D and manufacturing based on the customer's industry and application scenarios to help customers create more business opportunities.
The power consumption of the moving motor of the burner |
60W |
Burner angle |
(90 ° - 45 °), adjustable |
Ignition timing |
0 to 99.99 seconds arbitrarily set |
Ignition time |
horizontal 30s; vertical 10s |
Afterflame time, afterglow time timer |
0~99.99 seconds, accuracy: ±0.01 seconds; |
Flame height |
manually adjustable, and set a flame height scale of 20mm |
Use of gas |
industrial grade methane, liquefied petroleum gas, natural gas, gas, etc. (customer self-contained) |
Working power supply |
AC220V; 50Hz; 150W |
Q: Are you trading company or manufacturer ?
A: We are the manufactory ,in this area for 20years
Q: How long is your delivery time?
A: If the products in stock, generally 5-10 days,.if stockout 15-20 days ,according to the quantity of order.
Q: Do you provide samples ? is it free ?
A: Yes, we could offer the sample for your test , but its not free.Hope to understand the high cost of products for high quality
Q: What is your terms of payment ?
A: Payment amount<=1000USD, 100% in advance. Payment amount >=1000USD, 30% T/T in advance ,balance as the B/L copy
