-86℃ Chest Ultra-Low Temperature Medical Freezer
MDF-86V188E
To store virus, germs, blood plasma, vaccine, blood, skin, bone marrow, sperm, biological products, pelagic products and others.
Suitable for research institute, chemical, military, electronics, piscatorial industries, university labs, pelagic fishery industries and other areas
Temperature Control:
Microprocessor-based temperature controller, -40℃~-86℃ can be set freely, digital temperature display.
High and low temperature alarms, set as needed
Platinum resistance temperature sensor, temperature sensing accuracy
Safety
Alarms: high and low temperature alarms, sensor failure alarm.
Two alarm styles: buzzing, flashing
Keyboard lock, password protection function to avoid set parameter randomly
Operation parameters display, real-time monitoring, ensure the equipment safety stability
Refrigerating System
Imported branded compressor,low noise CFC-free, efficient environmental protection refrigerants
Thick and high density foam layer for thermal insulation
Using single cascade refrigeration system with optimized design, cooling speed, low power consumption, big refrigerating capacity
Humanized Design
Safety lock design prevents any abnormal door status
Wide voltage range, from 187V to 242V
Silent design, suitable for quite environment
Big screen display, easy to read
Double door seal design, lock the air conditioning, strengthen heat preservation effect
Mobile, fixed castor, convenience for the user
| -86°C ULT Freezer | Self-cascade system | ||||||
| Model | MDF-86V50 | MDF-86V188E | MDF-86V340E | MDF-86V408E | MDF-86V588E | MDF-86V838E | |
| Specificaitons | Shelf/drawer QTY | Stainless steel shelf/1 | Stainless steel shelf/2 | Stainless steel shelf/3 | Stainless steel shelf/3 | Stainless steel shelf/3 | Stainless steel shelf/3 |
| Cooling | Direct cooling | Direct cooling | Direct cooling | Direct cooling | Direct cooling | Direct cooling | |
| Defrost | Manual | Manual | Manual | Manual | Manual | Manual | |
| Refrigerant | Mixed-gas | Mixed-gas | Mixed-gas | Mixed-gas | Mixed-gas | Mixed-gas | |
| Power Consumption(kWh/24h) | 6.5 | 8.2 | 11.2 | 12 | 16.5 | 18.8 | |
| Noise(db) | 49.5 | 52 | 52 | 50 | 53 | 55 | |
| Ambient temperature(℃) | 10~32℃ | 10~32℃ | 10~32℃ | 10~32℃ | 10~32℃ | 10~32℃ | |
| Temperature range(℃) | -40~-86℃ | -40~-86℃ | -40~-86℃ | -40~-86℃ | -40~-86℃ | -40~-86℃ | |
| Cooling system | Compressor brand/QTY | SECOP/1 | CUBIGEL/1 | SECOP/1 | SECOP/1 | SECOP/2 | SECOP/2 |
| Sensor | PTC | PTC | PTC | PTC | PTC | PTC | |
| Temperature controller | Microprocessor | Microprocessor | Microprocessor | Microprocessor | Microprocessor | Microprocessor | |
| Display | Digital display | Digital display | Digital display | Digital display | Digital display | Digital display | |
| Power | Voltage/frequency(V/Hz) | 220/50Hz | 220/50Hz | 220/50Hz | 220/50Hz | 220/50Hz | 220/50Hz |
| Power(W) | 450W | 660W | 810W | 890W | 1500W | 1700W | |
| Current(A) | 3.1A | 4.3A | 5A | 4.6A | 9.1A | 9.8A | |
| Material | Inside material | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel |
| Outside material | Color sprayed steel | Color sprayed steel | Color sprayed steel | Color sprayed steel | Color sprayed steel | Color sprayed steel | |
| Insulation | PURF | PURF | PURF | PURF | PURF | PURF | |
| Size | Capacity(L/cu.ft) | 50/1.76 | 188/6.63 | 340/12 | 408/14.40 | 588/20.76 | 838/29.59 |
| NT./GT.(kg) | 75/95 | 207/222 | 268/288 | 268/293 | 303/332 | 391/424 | |
| Exterior size(W*D*H)(mm) | 540×620×1145 | 830×810×1607.5 | 854×1006×1907 | 872×1028×1945.5 | 872×1192×1994.5 | 1160×1172×1994.5 | |
| Interior size(W*D*H)(mm) | 361×429×406 | 465×465×830 | 488×607×1140 | 606×575×1180 | 606×738×1310 | 894×718×1310 | |
| Package size(W*D*H)(mm) | 690×760×1170 | 915×928×1818 | 935×1070×2128 | 954×955×2094 | 970×1138×2185 | 1212×1098×2185 | |
| Frozen Racks | Racks | 2(6X2) | 9(4X3) | 12(4X4) | 16(5X4,4X4) | 16(5X5) | 24(5X5) |
| Boxes (2 Inches) | 24 | 108 | 192 | 288 | 400 | 600 | |
| Samples(2ml) | 2400 | 10800 | 19200 | 28800 | 40000 | 60000 | |
| Alarm | High/low temperature | Y | Y | Y | Y | Y | Y |
| Power failure | / | Y | Y | Y | Y | Y | |
| Abnormal voltage | / | Y | Y | Y | Y | Y | |
| Sensor error | Y | Y | Y | Y | Y | Y | |
| Filter screen check | / | Y | Y | Y | Y | Y | |
| Thermostat failure | Y | Y | Y | Y | Y | Y | |
| Low battery | / | Y | Y | Y | Y | Y | |
| Condenser clean | / | Y | Y | Y | Y | Y | |
| High ambient temperature | / | Y | Y | Y | Y | Y | |
| Door ajar | / | Y | Y | Y | Y | Y | |
| Optional | Castor | Y | Y | Y | Y | Y | Y |
| Inside door | 1 | 3 | 2 | 2 | 2 | 2 | |
| Test hole QTY/diameter | / | 1/25MM | 1/25MM | 1/25MM | 1/25MM | 1/25MM | |
| USB port | / | / | Y | Y | Y | Y | |
| Chart recorder | / | / | / | / | / | / | |
| Data logger | Optional | Optional | Optional | Optional | Optional | Optional | |
| Power failure backup system(alarm) | / | 72h | 72h | 72h | 72h | 72h | |
| Remote alarm port | / | / | Y | Y | Y | Y | |
| CO2 back up system | / | Optional | Optional | Optional | Optional | Optional | |
| LN2 back up system | / | Optional | Optional | Optional | Optional | Optional | |
| Other | Certification | ISO.CE | ISO.CE | ISO.CE | ISO.CE | ISO.CE | ISO.CE |
