Brand Name Drawell
Place of Origin Shanghai, China
Model Number MDF-86V340

-86℃ Chest Ultra-Low Temperature Medical Freezer

MDF-86H458



To store virus, germs, blood plasma, vaccine, blood, skin, bone marrow, sperm, biological products, pelagic products and others.

Suitable for research institute, chemical, military, electronics, piscatorial industries, university labs, pelagic fishery industries and other areas





Temperature Control:

Microprocessor-based temperature controller, -40℃~-86℃ can be set freely, digital temperature display.

High and low temperature alarms, set as needed

Platinum resistance temperature sensor, temperature sensing accuracy



Safety

Alarms: high and low temperature alarms, sensor failure alarm.

Two alarm styles: buzzing, flashing

Keyboard lock, password protection function to avoid set parameter randomly

Operation parameters display, real-time monitoring, ensure the equipment safety stability



Refrigerating System

Imported branded compressor,low noise CFC-free, efficient environmental protection refrigerants

Thick and high density foam layer for thermal insulation

Using single cascade refrigeration system with optimized design, cooling speed, low power consumption, big refrigerating capacity



Humanized Design

Safety lock design prevents any abnormal door status

Wide voltage range, from 187V to 242V

Silent design, suitable for quite environment

Big screen display, easy to read

Double door seal design, lock the air conditioning, strengthen heat preservation effect

Mobile, fixed castor, convenience for the user



-86°C ULT Freezer Self-cascade system
  Model MDF-86V50 MDF-86V188E MDF-86V340E MDF-86V408E MDF-86V588E MDF-86V838E
Specificaitons Shelf/drawer QTY Stainless steel shelf/1 Stainless steel shelf/2 Stainless steel shelf/3 Stainless steel shelf/3 Stainless steel shelf/3 Stainless steel shelf/3
Cooling   Direct cooling  Direct cooling  Direct cooling        Direct cooling        Direct cooling        Direct cooling
Defrost Manual Manual   Manual   Manual   Manual   Manual
Refrigerant Mixed-gas Mixed-gas Mixed-gas Mixed-gas Mixed-gas Mixed-gas
Power Consumption(kWh/24h) 6.5 8.2 11.2 12 16.5 18.8
Noise(db) 49.5 52 52 50 53 55
Ambient temperature(℃) 10~32℃ 10~32℃ 10~32℃ 10~32℃ 10~32℃ 10~32℃
Temperature range(℃) -40~-86℃ -40~-86℃ -40~-86℃ -40~-86℃ -40~-86℃ -40~-86℃
Cooling system Compressor brand/QTY SECOP/1 CUBIGEL/1 SECOP/1 SECOP/1 SECOP/2 SECOP/2
Sensor PTC PTC PTC PTC PTC PTC
Temperature controller Microprocessor Microprocessor Microprocessor Microprocessor Microprocessor Microprocessor
Display Digital display Digital display Digital display Digital display Digital display Digital display
Power Voltage/frequency(V/Hz) 220/50Hz 220/50Hz 220/50Hz 220/50Hz 220/50Hz 220/50Hz
Power(W) 450W 660W 810W 890W 1500W 1700W
Current(A) 3.1A 4.3A 5A 4.6A 9.1A 9.8A
Material Inside material Stainless steel Stainless steel Stainless steel Stainless steel Stainless steel Stainless steel
Outside material Color sprayed steel Color sprayed steel Color sprayed steel Color sprayed steel Color sprayed steel Color sprayed steel
Insulation PURF PURF PURF PURF PURF PURF
Size Capacity(L/cu.ft) 50/1.76 188/6.63 340/12 408/14.40 588/20.76 838/29.59
NT./GT.(kg) 75/95 207/222 268/288 268/293 303/332 391/424
Exterior size(W*D*H)(mm) 540×620×1145 830×810×1607.5 854×1006×1907 872×1028×1945.5 872×1192×1994.5 1160×1172×1994.5
Interior size(W*D*H)(mm) 361×429×406 465×465×830 488×607×1140 606×575×1180 606×738×1310 894×718×1310
Package size(W*D*H)(mm) 690×760×1170 915×928×1818 935×1070×2128 954×955×2094 970×1138×2185 1212×1098×2185
Frozen Racks Racks 2(6X2) 9(4X3) 12(4X4) 16(5X4,4X4) 16(5X5) 24(5X5)
Boxes (2 Inches) 24 108 192 288 400 600
Samples(2ml) 2400 10800 19200 28800 40000 60000
Alarm High/low temperature Y Y Y Y Y Y
Power failure / Y Y Y Y Y
Abnormal voltage / Y Y Y Y Y
Sensor error Y Y Y Y Y Y
Filter screen check   / Y Y Y Y Y
Thermostat failure Y Y Y Y Y Y
Low battery / Y Y Y Y Y
Condenser clean / Y Y Y Y Y
High ambient temperature / Y Y Y Y Y
Door ajar / Y Y Y Y Y
Optional Castor Y Y Y Y Y Y
Inside door 1 3 2 2 2 2
Test hole QTY/diameter / 1/25MM 1/25MM 1/25MM 1/25MM 1/25MM
USB port / / Y Y Y Y
Chart recorder / / / / / /
Data logger Optional Optional Optional Optional Optional Optional
Power failure backup system(alarm) / 72h 72h 72h 72h 72h
Remote alarm port / / Y Y Y Y
CO2 back up system / Optional Optional Optional Optional Optional
LN2 back up system / Optional Optional Optional Optional Optional
Other Certification ISO.CE ISO.CE ISO.CE ISO.CE ISO.CE ISO.CE
