Microscope Binocular Electronics Use Binocular Microscope
BK5000 Series
ems | Specification | Outfits | |
Eyepiece | WF10×/20mm (23.2) | .. | |
Infinity Plan Objectives | PLAN 4×/0.10 | W.D.=12.10mm | . |
PLAN 10×/0.25 | W.D.=4.64mm | . | |
PLAN 20×/0.40(S) | W.D.=2.41mm | . | |
PLAN 40×/0.66(S) | W.D.=0.65mm | . | |
PLAN 100×/1.25(S, Oil) | W.D.=0.12mm | . | |
PLAN 2.5×/0.07 | W.D.=8.47mm | / | |
PLAN 60×/0.80(S) | W.D.=0.33mm | / | |
PLAN 100×/1.15(S, W) | W.D.=0.19mm | / | |
Seidentopf Binocular Head | Inclined 30°,Rotatable 360°, Interpupilary Distance: 48mm -75mm | . | |
Seidentopf Trinocular Head | Inclined 30°,Rotatable 360°, Interpupilary Distance: 48mm-75mm Light Distribution: 100: 0 / 80:20 | / | |
Nosepiece | Quintuple | . | |
Mechanical Stage | Stage Size: 175X145mm,Travel: 78mm×55mm | . | |
Swing Out Condenser | Abbe N.A. 1.25 with iris diaphragm. | . | |
Koehler Illumination Wide voltage input: 100V~240V Field diaphragm , center adjustable | 6V/20W Halogen Lamp | . | |
6V/30W Halogen Lamp |
| ||
3W-LED Illumination |
| ||
Filter | Blue | . | |
Green | / | ||
Amber | / | ||
Grey | / | ||
C-mount | 1×C-mount ( better for digital photograph) | / | |
0.57× C-Mount (focus adjustable, better for digital camera) | / | ||
Adaptor for Digital Photograph | Used for CANON/NIKON/OLYMPUS etc. | / | |
Fluorescence Attachment | Epi fluorescence unit ( six-hole disc media which can be fixed with Uv /V/B/G and another filters) ,100W mercury lamp. | / | |
Epi fluorescence unit ( six-hole disc media which can be fixed Uv /V/B/G), LED fluorescence lamp. | / | ||
Phase Contrast Unit | Quintuple hole turret 10× /20× /40× /100× phase contrast objective | / | |
Independent slot 10× /20× /40× /100× phase contrast objective | / | ||
Dark Field Unit | Dark field condenser (dry),apply to 4×- 40× objective | / | |
Dark field condenser (wet),apply to 100× objective | / | ||
Polarizing Attachment | Analyzer / Polarizer | / | |
Note: "."In Table Is Standard outfits, "/" Is Optional Accessories.
Packing Size: 565mm×310mm×410mm Gross Weight: 12 kgs Net Weight: 10kgs
