4w 1064nm IR Laser Source for Laser Marking
- 5000 Piece / Pieces per Month
- T/T Credit Card
You May Like
Product Details
Brand Name | CNI | Place of Origin | Jilin, China |
Product Description
FL-1064nm series laser combination of both DPSS and fiber technology, has the features of high peak power, high repetition rate, and short pulse duration, which is widely used in laser marking, engraving on the diamond, metal, Steel, IC, Plastics, and also in scientific research.
Features
40kW peak power, higher than ordinary fiber laser marking machine.
5ns short pulse duration, short acting time, low heat effect.
Small volume can match with market mainstream rack.
Scientific research quality standard, <1% power stability.
Industrial product flow, 12 quality inspection procedures, stable and reliable product quality.
Specifications for 1064nm Laser for marking metal | ||||||
Wavelength (nm) | 1064±1 | |||||
Work pattern | Q-switched | |||||
Model | FL-1064-4W | FL-532-3W | ||||
Average output power (W) | ~4W | ~6W | ||||
Pulse width (ns) | ~5ns | ~8ns | ||||
Peak power (kW) | ~40kW | |||||
Pulse repetition rate (kHz) | 10~20kHz | |||||
Power stability (rms, over 8 hours) | <1%,<2%,<3%,<5% | |||||
Transverse mode | TEM00 | |||||
Beam divergence, full angle (mrad) | <1.5mrad | <2mrad | ||||
Beam diameter at aperture (mm) | ~6.0mm | |||||
Beam height from base plate (mm) | 16.5mm | |||||
Operating Temp. (℃) | 0~40℃ | |||||
Laser head size | 297(L)× 45(W)× 53.8(H) mm3, 0.7 kg | |||||
Power supply(12VDC) | PSU-FL-OEM (12V/25A DC ) Portable power supply 225(L)×171(W)×73(H) mm3, 2.6kg | |||||
Expected lifetime (hours) | 20000 | |||||
Warranty | 1year |
Changchun New Industries (CNI) founded in 1996, located in Changchun, CHINA, is a leading manufacturer of solid-state and diode laser systems. Our products include UV laser, green laser, blue laser, yellow laser, red laser, RGB laser, infrared laser, single longitudinal mode laser and Q-switched laser systems. CNI lasers are featured with high performance, low cost and excellent laser beam quality, which are specifically designed for OEM, scientific, industrial and instrumentation use. In addition, CNI lasers are ISO-9001, FDA, CE and JQA certified.
CNI also provides laser components and accessories, we aim to offer customers complete laser solutions for all solid state lasers, diode lasers, laser marking system with our most convenient and rapid service.
