MSL-F-589 200mW Single Longitudinal mode 589nm yellow laser for Holography
APPLICATION:
All solid state single longitudinal mode yellow laser at 589 nm is made features of ultra compact, long lifetime, low cost and easy operating, which is used in DNA sequencing, flow cytometry, cell sorting, optical instrument, spectrum analysis, interference, measurement, holography, physics experiment, etc.
SPECIFICATIONS:
Wavelength (nm) | 589±1 |
Output power (mW) | 50,100,150,200 |
Transverse mode | Near TEM00 |
Longitude mode | Single |
Operating mode | CW |
Power Stability (rms,over 4 hours) | <3%,<5%,<10% |
Warm-up Time (minutes) | <10 |
M2 factor | <2.0 |
Beam divergence,full angle (mrad) | <2.0 |
Beam Diameter at the aperture (mm) | ~3.0 |
Beam height from base plate (mm) | 45 |
Spectral linewidth (nm) | < 0.00001 |
Pointing stability after warm-up (mrad) | <0.05 |
Noise of amplitude (rms,1~20MHz) | <0.5% |
Coherence length (m) | >50 |
Polarization ratio | > 100:1 |
Operating temperature(°C) | 15~35 |
Power supply (100-240VAC) | PSU-H-FDA |
Modulation | Modulation isn’t available. |
Expected lifetime (hours) | 10000 |
Warranty | 1 year |
Laser Head
PSU-H-LED Power supply
PSU-H-FDA Power supply
