CNI 532nm 2w green laser

FOB Price

USD $2,435 - $3,380 / Unit

1 Unit(Min.Order)

Product Details

Brand Name:

CNI

Place of Origin:

Jilin, China

Model Number:

OEM-F-532-2W

CNI 532nm 2w 3W green laser

APPLICATION:

It's easy to be installed in customers equipment.

SPECIFICAION:

Wavelength (nm)	532±1
Output power (mW)	>1, 5, 10, …, 450		500, 550, …, 1400	1500, …, 2000	2100, …, 3000
Transverse mode	TEM₀₀	Near TEM₀₀
Operating mode	CW
Power stability (rms, over 4 hours) at 25℃	<1%, <3%, <5%			<3%, <5%, 10%
Warm-up time (minutes)	<10
M² factor	<1.2		<1.2	<3.0	<3.0
Beam divergence, full angle (mrad)	<1.2
Beam diameter at the aperture (mm)	3-4
Beam height from base plate (mm)	25
Operating temperature (℃)	25+/-2
M² factor	0-2.5		0-5.5	0-5.5	0-8
Operating voltage of Diode(V)	~2.0
Pins information	11/12:positive of diode; 1/2: negative of diode		5/6/7/8: positive of diode; 12/13/14/15: negative of diode
Power supply (optional)	PSU-III-OEM (5VDC)		PSU-OEM-F (two channels 6 & 12V)
TTL modulation/ Analog modulation	TTL on/off, 1Hz-1KHz, 1KHz-10KHz, 10KHz-30KHz; and Analog modulation option
Expected lifetime (hours)	5000
Warranty time	The warranty is 3 months, excluding the LD failure.

OEM-F-532

136(L)×58(W) ×45(H) mm³, 0.74kg

F-532-HS

PSU-III-OEM (1-450mW) Accessories

100 (L) ×62(W) ×56 (H) mm3, 0.2kg 120(L)×60(W) ×37(H) mm³,100-240VAC

PSU-OEM-F(1-3000mW) Accessories

100(L)×76(W) ×27(H) mm³, 0.10 kg 160(L)×86.2(W) ×34.5(H) mm³100-240VAC
