Home > Products > brushed dc motors > 42zyt01a 12v 24v 15 watt dc motor permanent magnet 39mNm 3600rpm rated
42zyt01a 12v 24v 15 watt dc motor permanent magnet 39mNm 3600rpm rated
USD $5 - $15
/ Piece
5 Pieces(Min.Order)
- 100000 Piece / Pieces per Month
- SHANGHAI
- T/T Credit Card
You May Like
-
42mm 15w dc motor 12 volt or 24 volt equivalent to dunker motor
-
63mm 150watt 100watt electric motor dc brushed 12v 24v 40v
-
63WG worm gear dc automatic door motor sliding door opening and gate lifting
-
dc gear motor 12v 24v 40rpm 50rpm 60rpm 70rpm with different reduction
-
12v 24v 40nm dc motor with worm gear reductor OPTION 50Nm 60Nm
-
Planet dc Gearmotor 12V 24V high torque power 50w 100w 150w
Product Details
| Brand Name | Smart Automation | Place of Origin | Jiangsu, China | |
| Model Number | 42ZYT01 | Type | Micro Motor | |
| Certification | CE, ROHS | Torque | 39mNm ~ 100mNm | |
| Usage | Car, Electric Bicycle, Fan, Home Appliance | Construction | Permanent Magnet | |
| Efficiency | IE 1 | Protect Feature | Drip-proof | |
| Voltage(V) | 12v 24v 40v | Output Power | customed | |
| Continuous Current(A) | customed | Speed(RPM) | customed | |
| Commutation | Brush |
Product Description
Motor technical parameter:
Shaft HRC 36~40 ; NMB ball bearing
Hard ferrit magnet, 2- poles
Protection class IP 50
Insulation class: F, operating temperature range:-40°C~+140°C
CE and ROHS certified
Options:
Customized voltage, winding, shaft, mounting, and lead configurations
EMI/RFI suppression circuit; Thermal protection
High temperature Class H insulation
BELOW ARE ONLY TYPICAL MODELS.
WE CAN MAKE CUSTOMED SHAFT, PERFORMANCE AND MOTOR ADDERS
