US$ 10 - 26
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Brand Name:
Smart Automation
Place of Origin:
Jiangsu, China
Model Number:
63zyt
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
63ZYT02A dc Electric Motor 100w 12volt 24volt 3000rpmUS$ 8 - 30MOQ: 5 Pieces -
90zyt02 Series, dc Electric Motor 24v 500w 3000rpm, Option for 12vUS$ 30 - 80MOQ: 5 Pieces
-
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpmUS$ 11 - 25MOQ: 5 Pieces
-
76mm dc Gear Motor 12v 150w, 24v Option With Planet ReducerUS$ 40 - 100MOQ: 5 Pieces
-
12v 24v Electric dc Motor for Golf Cart 8Nm 150rpm LOW NOISEUS$ 25 - 60MOQ: 5 Pieces
Brand Name
Smart Automation
Place of Origin
Jiangsu, China
Model Number
63zyt
Type
Micro Motor
Certification
CE, ROHS
Torque
0.24N.m
Usage
Boat, Car, Fan, Home Appliance
Construction
Permanent Magnet
Efficiency
IE 1
Protect Feature
Explosion-proof
Voltage(V)
12v
Output Power
240w
Continuous Current(A)
customed
Speed(RPM)
9500rpm
Commutation
Brush
Motor technical parameter:
Shaft HRC 36~40 ; NMB ball bearing
Hard ferrit magnet, 2- poles
Protection class IP 00
Insulation class: b operating temperature range:-40°C~+140°C
CE and ROHS certified
Options:
Customized voltage, winding, shaft, mounting, and lead configurations
EMI/RFI suppression circuit; Thermal protection
High temperature Class H insulation
Rated voltage 12v 24v
No load 9500rpm
Rated torque 0.24Nm
Rated speed 8770rpm
Option for EMC
