Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm

Changzhou Smart Automation Motor Manufacturing Co., Ltd.
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm thumbnail-1
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm thumbnail-2
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm thumbnail-3
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm thumbnail-4
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm thumbnail-5
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm thumbnail-6
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm photo-1
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm photo-2
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm photo-3
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm photo-4
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm photo-5
Dia. 63mm Massage Chair Motor, DC 24 Volt, 12 Volt 4000rpm photo-6
US$ 11 - 25 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Brand Name:
Smart Automation
Place of Origin:
China
Model Number:
63ZYT01b
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Smart Automation
Place of Origin China
Model Number 63ZYT01b
Type Micro Motor
Certification CE, ROHS
Torque 0.2N.m
Usage Car, Electric Bicycle, Fan, Home Appliance
Construction Permanent Magnet
Efficiency IE 1
Protect Feature Drip-proof
Continuous Current(A) customed
Speed(RPM) 4000rpm
Commutation Brush



Dia. 63mm massage chair motor, DC 24 volt, 12 volt



Motor technical parameter:

Shaft HRC 36~40 ; NMB ball bearing

Hard ferrit magnet, 2- poles

Protection class IP 50

Insulation class: F, operating temperature range:-40°C~+140°C

 CE and ROHS certified

Options:

 Customized voltage, winding, shaft, mounting, and lead configurations

 EMI/RFI suppression circuit; Thermal protection

 High temperature Class H insulation





Model

63ZYT01B-12V

63ZYT01B-24V

63ZYT01B-40V

Rated voltage

V dc

12

24

40

Continuous rated speed

rpm

4000

4000

4000

Continuous rated torque

N.m

0.2

0.2

0.2

Continuous current

A

10.0

4.9

2.8

Starting torque

N.m

1.12

1.41

1.46

Starting current

A

50.8

30.8

17.8

No load speed

rpm

4700

47000

4900

No load current

A

1.0

0.6

0.4

Demagnetization current

A

67.6

41.0

23.7

Rotor inertia

gcm2

400

400

400

weight

g

1000

1000

1000

motor length

mm

95

95

95
