Home > Electrical & Electronics > Electric Motor > DC Motor > 42ZYT02A 12v 24v dc Motor 57mNm 3100rpm 20w

42ZYT02A 12v 24v dc Motor 57mNm 3100rpm 20w

Name: 42ZYT02A 12v 24v dc Motor 57mNm 3100rpm 20w
Brand: Smart Automation
SKU: 166314961
Availability: InStock

42ZYT02A 12v 24v dc Motor 57mNm 3100rpm 20w thumbnail-1

42ZYT02A 12v 24v dc Motor 57mNm 3100rpm 20w thumbnail-2

42ZYT02A 12v 24v dc Motor 57mNm 3100rpm 20w thumbnail-3

42ZYT02A 12v 24v dc Motor 57mNm 3100rpm 20w photo-1

42ZYT02A 12v 24v dc Motor 57mNm 3100rpm 20w photo-2

42ZYT02A 12v 24v dc Motor 57mNm 3100rpm 20w photo-3

US$ 6 - 15 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Brand Name:

Smart Automation

Place of Origin:

Jiangsu, China

Model Number:

42ZYT02A

Contact Supplier Request Quote Chat Now

Changzhou Smart Automation Motor Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name Smart Automation

Place of Origin Jiangsu, China

Model Number 42ZYT02A

Type Micro Motor

Certification CE, ROHS

Torque 57mNm

Usage Car, Electric Bicycle, Fan, Home Appliance

Construction Permanent Magnet

Protect Feature Drip-proof

Voltage(V) 12v, 24v~40v

Output Power 20w

Continuous Current(A) customed

Speed(RPM) 3100~3700rpm

Commutation Brush

Permanent Magnet Brush DC Motor 42ZYT02A

Motor Specifications

Shaft materials 3Cr13, HRC 36~40

High quality ball bearing

Hard ferrite magnet, 2- poles

Protection class IP 50

Insulation class: F, operating temperature range:-40°C~+140°C

CE and ROHS certified

Options

Customized voltage, winding, shaft, mounting, and lead configurations

EMI/RFI suppression circuit; Thermal protection, high temperature Class H insulation

Model	42ZYT02A
Rated voltage	V dc	12	24	40
Continuous rated speed	rpm	3750	3100	3400
Continuous rated torque	mN.m	53	57	57
Continuous current	A	2.7	1.2	0.8
Starting torque	mN.m	320	330	360
Starting current	A	13.2	5.68	3.97
No load speed	rpm	4550	3800	3950
No load current	A	0.44	0.18	0.12
Demagnetization current	A	24	10.5	6.3
Rotor inertia	Gcm2	110	110	110
Weight of motor	g	490	490	490
Motor length	Mm	80	80	80
