63ZYT02A high torque Brushed 3000rpm dc Motor, rated 0.31Nm 100W
- 100000 Piece / Pieces per Month
- SHANGHAI
- T/T Credit Card
-
63ZYT03A high torque Brushed electric dc Motor, rated 0.40Nm 3000rpm 126W
-
12v 24v 48v dc pump motor used for hydraulic water air pumps
-
3'' 76mm Permanent Magnet Brush Dc Motor catalogue
-
63mm Permanent Magnet Brushed DC Engine rated 12V 24V 36v 48V replace Gr63
-
63mm brushed high torque 12v dc motor ; 24v dc motor
-
63ZYT01B 12 volt 24 volt rated 4000rpm 75w dc motor manufacturers
Product Details
| Brand Name: | SmartAutomation | Place of Origin: | China | Model Number: | 63ZYT02A |
| Type: | Micro Motor | Certification: | CE, ROHS | Torque: | 0.31N.m |
| Usage: | Car, Electric Bicycle, Fan, Home Appliance | Construction: | Permanent Magnet | Efficiency: | IE 1 |
| Protect Feature: | Drip-proof | Voltage(V): | 12v, 24v~40v | Output Power: | 100w |
| Continuous Current(A): | customed | Speed(RPM): | 3000rpm | Commutation: | Brush |
Product Description
Motor technical parameter:
Shaft HRC 36~40 ; NMB ball bearing
Hard ferrit magnet, 2- poles
Protection class IP 50
Insulation class: F, operating temperature range:-40°C~+140°C
CE and ROHS certified
Options:
Customized voltage, winding, shaft, mounting, and lead configurations
EMI/RFI suppression circuit; Thermal protection
High temperature Class H insulation
Model | 63ZYT02A | |||
Rated voltage | V dc | 12 | 24 | 40 |
Continuous rated speed | rpm | 3000 | 3000 | 3000 |
Continuous rated torque | mN.m | 310 | 310 | 310 |
Continuous current | A | 11.5 | 5.8 | 3.5 |
Starting torque | mN.m | 2000 | 2000 | 2000 |
Starting current | A | 59 | 29.5 | 17.5 |
No load speed | rpm | 3500 | 3500 | 3500 |
No load current | A | 2.0 | 1.2 | 0.8 |
Demagnetization current | A | 110 | 55 | 33 |
Rotor inertia | Gcm2 | 600 | 600 | 600 |
Weight of motor | g | 1200 | 1200 | 1200 |
Motor length | mm | 110 | 110 | 110 |
