PVC insulated twisted electric wire
It is manufactured according to GB/T5023-2008 (the same as IEC60227), JB8734-1998 Standard. It is suitable to be used in power equipment, daily used electrical appliance, instruments and so on with rated voltage up to 450/750V.
This series of electrical wires include models as below:
Type |
Description |
RV |
Copper Core PVC Insulation Flexible Wire |
RVB |
Copper Core PVC Insulation Flat Flexible Wire |
RVS |
Copper Core PVC Insulation Twisted Flexible Wire |
RVV |
Copper Core PVC Insulation Sheath Round Flexible Wire |
RVVB |
Copper Core PVC Insulation Sheath Flat Flexible Wire |
6, Main technical parameter
|
No. of core* Nominal Area sqmm |
No.& Wire Dia mm |
Thickness of insulation mm |
Max. Overall Dia mm |
Resistance at 20°C Ohm/km |
Min.Insulation Resistance at 70°CMohm/km |
Total Weight kg/km |
2*0.3 |
16/0.15 |
0.6 |
4.3 |
69.2 |
0.016 |
1.2 |
2*0.4 |
23/0.15 |
0.6 |
4.6 |
48.2 |
0.014 |
1.5 |
2*0.5 |
28/0.15 |
0.6 |
5.8 |
39 |
0.016 |
1.8 |
2*0.75 |
42/0.15 |
0.8 |
6.2 |
26 |
0.014 |
2.7 |
2*1.0 |
32/0.20 |
0.8 |
6.8 |
19.5 |
0.010 |
3.5 |
2*1.5 |
30/0.25 |
0.8 |
7.4 |
13.3 |
0.010 |
4.6 |
