450/750V copper electric cable wire
- 20 Kilometer / Kilometers per Month
- qingdao
- T/T Credit Card
You May Like
Product Details
Brand Name | shuangjia | Place of Origin | Henan, China | |
Model Number | BV, BVV | Type | Insulated | |
Application | Overhead | Insulation Material | PVC | |
Conductor Material | Copper | Conductor Type | Solid |
Product Description
450/750V copper electric cable wire Include:
1) Copper (aluminium) conductor PVC insulated wires (BV)
2) Copper conductor PVC insulated flexible wires (BVR)
3) Copper (aluminium) conductor PVC insulated PVC sheathed round wires
4) Copper (aluminium) conductor PVC insulated PVC sheathed flat wires
5) Copper conductor PVC insulated flat and flexible connectors
6) Copper conductor PVC insulated PVC sheathed round and flexible connectors
Size: 0.5-185 mm2
Usage:
This prodcut is widely used in the construction of buildings airports, power transportation, urban and rural power network reformation and other main projects.
copper building wire Include following code and specification
Nominal | Conductor | Nominal | Max overall | Condcutor | Min insulated | Weight | ||
Cu | Al | Cu | Al | |||||
1.5 | 1/1.38 | 0.7 | 3.3 | 12.1 | - | 0.011 | 19.2 | - |
1.5 | 7/0.52 | 0.7 | 3.5 | 12.1 | - | 0.010 | 20.6 | - |
2.5 | 1/1.78 | 0.8 | 3.9 | 7.41 | 11.8 | 0.010 | 30.8 | 15.0 |
4 | 1/2.25 | 0.8 | 4.4 | 4.61 | 7.39 | 0.0085 | 45.5 | 21.0 |
6 | 1/2.76 | 0.8 | 4.9 | 3.08 | 4.91 | 0.0070 | 65.0 | 29.0 |
10 | 7/1.35 | 1.0 | 7.0 | 1.83 | 3.08 | 0.0065 | 110.0 | 52.0 |
16 | 7/1.70 | 1.0 | 8.0 | 1.15 | 1.91 | 0.0050 | 170.0 | 70.0 |
We would like to introduce ourselves as an ISO9001/14001/18001 ,CCC ,UL certificated Manufacturer of different kinds of Cables ,our products have exported to more than 50 countries .
Henan Huaxing Cables and Wires Company .Ltd ,was found in 1984 and expanded in 2005, the workshop covers an area of 67,000m2, building area is about 28,000m2,,more than 260 employees , We serve under the skillful & experienced management which provide effective & efficient service to you.
We are also the Long term supplier of Ministry of Electric power of Yemen ,National Electric Energy Agency of Italy ,Electric power company of France, numbers of listed companies already established long business relationship with us .
Our hot products including Aluminum Rod ,All Aluminum Conductor( AAC),All Aluminum Alloy Conductor (AAAC),Aluminum Conductor Steel Reinforced(ASCR), Aerial Cable, Concentric Cable ,Power Cable ,PV Cable ,Electric Wire and so on;
1) Wrapped in rolls/coils/rings with Plastic film for small diameter cables like building wires.
2) Cables are normally supplied in lengths of 100 meters,500 meters and 1000 meters according to cable size.Other length could be supplied if required.
3) Treated wooden/steel-wooden drums for big diameter cables.
