Electric wires with rubber insulation is suitable for AC rated voltage U/U300/500 V and below on electrical equipment or lighting in stalling.
1.Specifications :0.5-240 mm 2 (1-5 )core
2.Usage:
This rubber sheath electric wire is applicable to the welding machine cable secondary side wiring and connecting cables for the electric welding clamp, the exchange rated voltage not exceeding 380 V DC and pulse peak 450 V. For a single-core structure, a multi-unit made of soft wire-cutter. Conductive core line outside a thermally insulated with polyester film around the package, with the outer layer made of rubber insulation and jacket as a protective layer.
3.Simple specification
|
Cores No./nominal section area (No./mm2) |
Conductor Strands No. and single wire diameter (No./mm) |
Insulated thickness (mm) |
Sheath Thickness (mm) |
Approx. Diameter (mm) |
Approx. Weight (kg/km)
|
2x0.75 |
24/0.20 |
0.6 |
0.8 |
8.2 |
62.8 |
2x1.5 |
30/0.25 |
0.8 |
1.0 |
10.5 |
110.6 |
2x2.5 |
50/0.25 |
0.9 |
1.1 |
12.5 |
156.3 |
2x6 |
84/0.30 |
1.0 |
1.3 |
17.0 |
296.3 |
3x1 |
32/0.20 |
0.6 |
0.9 |
9.2 |
102.3 |
3x1.5 |
30/0.25 |
0.8 |
1.0 |
11.0 |
132.7 |
3x2.5 |
50/0.25 |
0.9 |
1.1 |
13.0 |
189.9 |
3x4 |
56/0.30 |
1.0 |
1.2 |
14.5 |
273.1 |
3x6 |
84/0.30 |
1.0 |
1.3 |
18.0 |
367.4 |
4x0.75 |
24/0.20 |
0.6 |
0.9 |
10.0 |
108.0 |
4x1.5 |
30/0.25 |
0.8 |
1.1 |
12.5 |
170.7 |
4x2.5 |
56/0.25 |
0.9 |
1.2 |
14.0 |
237.3 |
4x4 |
56/0.30 |
1.0 |
1.3 |
16.5 |
342.2 |
4x6 |
84/0.30 |
1.0 |
1.4 |
20.0 |
461.0 |
3x1.5+1x1 |
30/0.25+32/0.20 |
0.8/0.6 |
1.1 |
12.0 |
153.3 |
3x2.5+1x1.5 |
50/0.25+30/0.25 |
0.9/0.6 |
1.2 |
14.0 |
220.5 |
5x0.75 |
24/0.20 |
0.6 |
1.0 |
11.0 |
114.4 |
5x1.5 |
30/0.25 |
0.8 |
1.1 |
13.5 |
196.1 |
5x2.5 |
50/0.25 |
0.9 |
1.3 |
15.5 |
288.0 |
5x4 |
56/0.30 |
1.0 |
1.4 |
18.0 |
415.5 |
5x6 |
84/0.30 |
1.0 |
1.6 |
22.5 |
568.0 |
