Factory supply aluminium rod for cable manufacture
USD $2,000 - $2,500
/ Ton
1000 Tons(Min.Order)
- 50000 Kilometer / Kilometers per Month
- qingdao
- T/T Credit Card
You May Like
Product Details
| Brand Name | shuangjia | Place of Origin | Henan, China | |
| Shape | Round | Application | power cable industry material | |
| Surface Treatment | Polished | Technique | Cold Drawn | |
| Temper | O - H112 | Al (Min) | 99.7 | |
| Alloy Or Not | Non-alloy | Grade | 1000 Series |
Product Description
Alloy for electrical purposes-Temper for delivery-Mechanical and electrical characteristics | ||||||
alloy designation | Temper | Mechanical characteristic | (Resistivity)Ω mm²m Max | (Conductivity)%IACS Min | ||
(Tensile strength)Mpa | (Elongation)% | |||||
Min | Max | |||||
EN AW-1370[EAL99,7] and EN AW-1350[EAL99,5] | H14 | 110 | 130 | 8 | 0.02801 | 61.5 |
H13 | 105 | 120 | 12 | 0.02801 | 61.5 | |
H12 | 95 | 110 | 14 | 0.02785 | 61.5 | |
H11 | 80 | 95 | 25 | 0.02755 | 61.9 | |
Packing |
|
| ||||
Outer diameter | 1360mm±50mm | 1350mm±50mm | ||||
Inner diameter | 760mm±30mm | 600mm±30mm | ||||
Width | 890mm±30mm | 880mm±30mm | ||||
