Features :
This product not only has the characteristics of ordinary PVC insulated power cable and low voltage crosslinked power cable, but also has the following characteristics:
1. it has low and uniform positive (negative) sequence and zero sequence impedance, which is beneficial to improve the quality of power supply.
2. The reactance of concentric conductor is much lower than that of the fourth core of ordinary four-core cable under zero sequence. It is beneficial to the sensitive action of short circuit automatic protection device. So as to ensure the safe operation of cables and related equipment.
3. It has strong anti-electromagnetic interference performance and lightning strike resistance.
4. Five-core cable is suitable for power supply of TN-S and TN-C-S systems
Working Conditions :
1.Max .Working temperature of conductor for long term application,70℃ for PVC Insulated type ,90℃ for XLPE insulated type ;
2.1.Max .Working temperature of conductor during short circuit :160℃ for PVC Insulated type ,250℃ for XLPE insulated type ;in addition ,the longest lasting time for short circuit is 5 seconds .
3. Min Ambient Temperature during laying:0℃
4.Min Bending Radius :20 times of overall diameter for single core type ,and 15 times of overall diameter of muti-core type .
| Type | Core | Nominal Area mm2 |
| VV-T,VLV-T,ZR-VV-T,ZR-VLV-T,YJV-T,YJLV-T,Z-YJV-T, ZR-YJLV-T,VV22-T VLV22-T,ZR-VV22-T,ZR-VLV22-T,YJV22-T YJLV22-T,ZR-YJV22-T,ZR-YJLV22-T | 3+1(T) | 4~300 |
| 3+1+1(T) | 4~185 | |
| 4+1(T) | 4~185 |
| Speicfication | Conductor Diameter mm | Overall Diameter mm | Cauculated Weight kg/km | ||||
| mm2 | VV-T VLV-T | VV22-T VLV22-T | VV-T | VLV-T | VV22-T | VLV22-T | |
| 3×4+1×2.5(T) 3×6+1×4(T) 3×10+1×6(T) 3×16+1×10(T) 3×25+1×16(T) 3×35+1×25(T) 3×50+1×25(T) 3×70+1×35(T) 3×95+1×50(T) 3×120+1×70(T) 3×150+1×95(T) 3×185+1×120(T) 3×240+1×150(T) 3×300+1×150(T) 3×4+1×4(T) 3×6+1×6(T) | 2.25 2.76 3.55 4.8 6.0 7.0 8.3 10.0 11.6 13.0 14.6 16.2 18.4 20.6 2.25 2.76 | 18.2 19.3 22.1 24.9 28.6 27.5 30.8 34.5 39.9 42.7 47.6 52.1 59.0 64.1 18.2 19.3 | 21.8 22.9 25.7 28.7 32.6 31.5 35.6 39.1 44.9 47.9 53.0 57.5 64.6 70.1 21.8 22.9 | 419 515 662 976 1380 1561 2028 2762 3753 4657 5595 6996 9000 11181 440 525 | 344 403 472 676 905 942 1154 1506 2007 2457 2886 3607 4597 5621 365 413 | 714 827 1018 1389 1865 2028 2772 3572 4725 5586 6571 8098 10503 12874 735 836 | 639 715 828 1088 1390 1409 1898 2316 2753 3386 3862 4916 5733 7314 660 724 |
This product is manufactured according to enterprise standards. The products are suitable for transmission of electric energy in power lines with rated voltage 0.6/1kV and below. They are widely used in petrochemical, metallurgy, mining and other occasions of high-rise buildings.
We would like to introduce ourselves as an ISO9001/14001/18001 ,CCC ,UL certificated Manufacturer of different kinds of Cables ,our products have exported to more than 50 countries .
Henan Huaxing Cables and Wires Company .Ltd ,was found in 1984 and expanded in 2005, the workshop covers an area of 67,000m2, building area is about 28,000m2,,more than 260 employees , We serve under the skillful & experienced management which provide effective & efficient service to you.
We are also the Long term supplier of Ministry of Electric power of Yemen ,National Electric Energy Agency of Italy ,Electric power company of France, numbers of listed companies already established long business relationship with us .
Our hot products including Aluminum Rod ,All Aluminum Conductor( AAC),All Aluminum Alloy Conductor (AAAC),Aluminum Conductor Steel Reinforced(ASCR), Aerial Cable, Concentric Cable ,Power Cable ,PV Cable ,Electric Wire and so on;
1) Wrapped in rolls/coils/rings with Plastic film for small diameter cables like building wires.
2) Cables are normally supplied in lengths of 100 meters,500 meters and 1000 meters according to cable size.Other length could be supplied if required.
3) Treated wooden/steel-wooden drums for big diameter cables.
