11KV 22KV 33KV aluminium armoured cable with pvc sheaeth is Features:
a) Rated voltage UO / U: 0.6 / 1kV
b) Max. long term operating temperature of cable conductor:
1) XLPE insulation: 90° C
2) PVC insulation: 70° C
c) Environment temperature in laying the cable should not be lower than 250° C
d) The min. bending radius should be more than 15 times than the outer diameter of the cable e) DC conductor resistance complies with the stipulations of GB / T3956
f) Working frequently under voltage test for cable with 3.5kV / 5min. without puncture
g) Lower smoke & halogen, free flame, retardant cable could endure firing test in
bundle as GB / T18380.3 and smoke density in firing complies with stimulation GB / T 17651.1
1/15/35KV aluminium armoured cable Include following code and specification
Code Word |
AWG or Kcmil |
Bare Neutral Messenger |
Phase Conductor |
Weight |
||
AL.-ALLOY Stranding and wires Dia(mm) |
Rated strength(lbs) |
Al. Stranding and wires Dia(mm) |
XLPE Insulated thickness(mm) |
(kg/km) |
||
Minex |
2*6AWG+1*30.58 |
7/1.68 |
1110 |
1/4.11 |
1.14 |
152 |
prawn |
2*4AWG+1*48.69 |
7/2.12 |
1760 |
1/5.19 |
1.14 |
229 |
Shrimp |
2*2AWG+1*77.47 |
7/2.67 |
2800 |
7/2.47 |
1.14 |
354 |
Cammarus |
2*1/0AWG+1*123.3 |
7/3.37 |
4460 |
7/3.12 |
1.52 |
569 |
Dungeness |
2*2/0AWG+1*155.4 |
7/3.78 |
5390 |
7/3.50 |
1.52 |
702 |
Cyclops |
2*3/0awg+1*155.4 |
7/3.78 |
5390 |
19/2.13 |
1.52 |
703 |
Flustra |
2*3/0AWG+1*195.7 |
7/4.25 |
6790 |
19/2.39 |
1.52 |
869 |
LEPAS |
2*4/0AWG+1*246.9 |
7/4.77 |
8560 |
19/2.68 |
1.52 |
1077 |
CRAB |
2*4AWG+1*30.58 |
7/1.68 |
1110 |
7/1.96 |
1.14 |
208 |
SDCRAB |
2*1/0AWG+1*77.47 |
7/2.67 |
2800 |
7/3.12 |
1.52 |
504 |
MOQ, Capacity& Payment method
For electric wire, aerial cable and power cable, the Minimum Order Quantity is 1000 meters each type. The capacity is 20 kilometers per day.
Our payment term is 30% deposit in advance, 70% rest against copy of B/L; or 100% irrevocable L/C at sight
Packing Pictures:
