Help CenterOverhead Cable,ABC Cable With Aluminum Core XLPE Insulated
Related Products
-
ABC CableUS$ 0.1 - 2MOQ: 1 Meter -
ABC Overhead Electric CableUS$ 0.1 - 2.5MOQ: 1 Meter
-
Aluminium Cable 185,aluminium Conductor 185mm2US$ 0.5 - 2.5MOQ: 1000 Meters
-
4 Core 16mm, 25mm, 35mm Abc Cable SupplierUS$ 0.5 - 3.6MOQ: 1000 Meters
-
0.6/1kV Hot Sale ABC Cable Aluminum WireUS$ 0.1 - 10.9MOQ: 1 Meter
Type and Application
a. Duplex Service Drop Application:To supply 120 volt aerial service for temporary service at construction sites,outdoor or street lighting. For service at 600 volts or lower at a conductor temperature of 75°C maximum.
b. Triplex Service Drop
Application: To supply power from the utility's lines to the consumer's weatherhead. For service at 600 volt or less (phase to phase) at a conductor temperature of 75°C maximum for polyethylene insulation 90°C maximum for crosslinked insulation.
c. Quadruplex Service Drop.
Used to supply 3 phase power, usually from a polemounted transformer, to the user's service head where connection to the service entrance cable is made. To be used at voltages of 600 volts or less phase to phase and at conductor temperatures not to exceed 75°C for polyethylene insulation 90°C maximum for crosslinked polyethylene(XLPE) insulated conductors.
Code Word |
AWG or Kcmil |
Bare Neutral Messenger |
Phase Conductor |
Weight |
||
AL.-ALLOY Stranding and wires Dia(mm) |
Rated strength(lbs) |
Al. Stranding and wires Dia(mm) |
XLPE Insulated thickness(mm) |
(kg/km) |
||
Minex |
2*6AWG+1*30.58 |
7/1.68 |
1110 |
1/4.11 |
1.14 |
152 |
prawn |
2*4AWG+1*48.69 |
7/2.12 |
1760 |
1/5.19 |
1.14 |
229 |
Shrimp |
2*2AWG+1*77.47 |
7/2.67 |
2800 |
7/2.47 |
1.14 |
354 |
Cammarus |
2*1/0AWG+1*123.3 |
7/3.37 |
4460 |
7/3.12 |
1.52 |
569 |
Dungeness |
2*2/0AWG+1*155.4 |
7/3.78 |
5390 |
7/3.50 |
1.52 |
702 |
Cyclops |
2*3/0awg+1*155.4 |
7/3.78 |
5390 |
19/2.13 |
1.52 |
703 |
Flustra |
2*3/0AWG+1*195.7 |
7/4.25 |
6790 |
19/2.39 |
1.52 |
869 |
LEPAS |
2*4/0AWG+1*246.9 |
7/4.77 |
8560 |
19/2.68 |
1.52 |
1077 |
CRAB |
2*4AWG+1*30.58 |
7/1.68 |
1110 |
7/1.96 |
1.14 |
208 |
SDCRAB |
2*1/0AWG+1*77.47 |
7/2.67 |
2800 |
7/3.12 |
1.52 |
504 |
We can also deliver cable to your particular requirements. If you are interested, pllease feel free to contact with me.
